Delem Synchronize Electric Hydraulic Press Brake , WE67K Press Brake Machine
Delem Synchronize Electric Hydraulic Press Brake , WE67K Press Brake Machine
Delem Synchronize Electric Hydraulic Press Brake , WE67K Press Brake Machine
Delem Synchronize Electric Hydraulic Press Brake , WE67K Press Brake Machine
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
WC67Y
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
5 sets per month
Delivery Time :
25 working days
Packaging Details :
Wooden box, standard sea packing
Pressure :
100tons
Machine Width :
3200mm
Control system :
Delem DA56
Seal ring :
Valque
Hydraulic valve :
Rexroth
Machine name :
Press Brake
Description

Synchronize Electric Hydraulic Press Brake

WE67K Press Brake Machine

DELEM CNC Bending Machine

Hydraulic Press Brake

Type
Back-gauge range
Ram strokes
Maximum open
Power
WC67K-63T2500
20-600mm
120mm
370mm
5.5kw
WC67K-125t4000
20-600mm
120mm
380mm
7.5kw
WC67K-100t3200
20-600mm
120mm
380mm
7.5kw
Dimension
Throat depth
Poles distance
Worktable length
Nominal force
2700*1380*2250
260mm
2000mm
2500mm
630KN
4200*1550*2450
320mm
3055mm
4000mm
1250KN
3400*1500*2420
320mm
2500mm
3200mm
1000KN


1. Special numeric-control system is fitted with mainframe of the bending machine.

2. Multi-work-step programming function is able to achieve an automatic operation and contnuous positioning of multi-step procedures, as well as an automatic precision adjustment for positions of rear stopper and gliding block.

3. The machine is provided with bend counting function, for a real-time display of processing quantity and power-failure memory of positions of stopper and gliding block, as well as procedures and parameters.

4. Imported ball bearing lead screw and linear guide rail are used for rear stopper, to ensure the positioning precision of rear stopper, for processing precision of machine to be higher.
