SKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup Width
SKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup Width
SKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup Width
SKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup Width
SKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup Width
SKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup Width
SKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup Width
SKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup Width
Specifications
Brand Name :
SKF
Model Number :
33018/Q
MOQ :
1
Price :
USD 0.5-10 PCS
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000 PCS/MON
Delivery Time :
3-15 DAYS
Packaging Details :
Single Box , Industrial Packing
Description

SKF Metric taper roller bearing priced cup & cone together 90mm inside x 140mm outside x 39mm width

SKF Taper roller bearings have tapered inner and outer ring raceways between which tapered rollers are arranged. The projection lines of all the tapered surfaces meet at a common point on the bearing axis. Their design makes taper roller bearings particularly suitable for the accommodation of combined (radial and axial) loads.
Taper roller bearings are generally separable, i.e. the cone, consisting of the inner ring with roller and cage assembly, can be mounted separately from the cup (outer ring).
SKF taper roller bearings have the logarithmic contact profile that provides optimum stress distribution over the roller/raceway contacts. The special design of the sliding surfaces of the guide flange and large roller ends considerably promote lubricant film formation in the roller end/flange contacts. The resulting benefits include increased operational reliability and reduced sensitivity to misalignment.

DIMENSIONS

d
90 mm
 Bore diameter
D
140 mm
 Outside diameter
T
39 mm
 Total bearing width
d1
≈114 mm
 Inner ring shoulder diameter
B
39 mm
 Width inner ring
C
32.5 mm
 Width outer ring
r1,2
min.2 mm
 Corner radius inner ring
r3,4
min.1.5 mm
 Corner radius outer ring
a
27.389 mm
 Distance pressure point

ABUTMENT DIMENSIONS

da
max.101 mm
 Abutment diameter shaft
db
min.101 mm
 Abutment diameter shaft
Da
min.127 mm
 Abutment diameter housing
Da
max.131 mm
 Abutment diameter housing
Db
min.135 mm
 Abutment diameter housing
Ca
min.7 mm
 Abutment housing - axial space at the large side face/ both sides of the outer ring
Cb
min.6.5 mm
 Abutment housing - axial space at the small side face/ both sides of the outer ring
ra
max.2 mm
 Fillet radius
rb
max.1.5 mm
 Fillet radius

CALCULATION DATA

Basic dynamic load rating C
266 kN
Basic static load rating C0
355 kN
Fatigue load limit Pu
39 kN
Reference speed
3 600 r/min
Limiting speed
4 500 r/min
Calculation factor e
0.27
Calculation factor Y
2.2
Calculation factor Y0
1.3

MASS

Mass bearing
2.2 kg

SKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup WidthSKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup Width

Product Picture

SKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup WidthSKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup WidthSKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup WidthSKF 33018/Q Tapered Roller Bearing Full Assembly - 90 mm Bore, 140 mm OD, 39 mm Cone Width, 32.5 mm Cup Width

Packing , Payment , Delievry and Stock

Packaging
1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
2)Industrial Bearings packaging a)plastic tube + carton + pallet
b). plastic bag +kraft paper + carton + pallet
3)According to the requirement of customers'
Payment
1) T/T:30% deposit, 70% should be paid before shipment.
2) L/C at sight. (high bank charge, not suggest, but acceptable )
3) 100% Western Union in advance. (especially for air shipment or small amount)
Delivery
1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
Stock
1)Availability and supply capacity on a certain basis
