LM 29749 NTN Tapered Roller Bearing Cone - 1.5000 in ID, 0.7200 in Cone Width,
LM 29749 NTN Tapered Roller Bearing Cone - 1.5000 in ID, 0.7200 in Cone Width,
LM 29749 NTN Tapered Roller Bearing Cone - 1.5000 in ID, 0.7200 in Cone Width,
LM 29749 NTN Tapered Roller Bearing Cone - 1.5000 in ID, 0.7200 in Cone Width,
LM 29749 NTN Tapered Roller Bearing Cone - 1.5000 in ID, 0.7200 in Cone Width,
LM 29749 NTN Tapered Roller Bearing Cone - 1.5000 in ID, 0.7200 in Cone Width,
Specifications
Brand Name :
NTN
Model Number :
LM 29749
MOQ :
1
Price :
USD 0.5-10 PCS
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 PCS/MON
Delivery Time :
3-15 DAYS
Packaging Details :
Single Box , Industrial Packing
Bearing Model :
LM 29749
Bearing Type :
Taper Roller Bearing
Precision rating :
ABEC1, P0
Dynamic Load Capacity :
9800 lbf
Description

LM29749/LM29711 bearing, TS series, single row tapered roller bearing

Bearing Type : Tapered Roller Bearing

Brand : NTN

Cage material : Steel Cage

Material : Case Carburized Steel

Finish/Coating : Uncoated

Scope application : Industria and Construction Machinery

Inner Packing : Carton/wooden box, packaging with a woven belt

Outer Packing : Carton/wooden box

Stock : Great Supplying Ability

Supply a sample : Yes

Bearing Specification

Bore Diameter 1.5000 in
Cone Width 0.7200 in
Bearing Material Case Carburized Steel
Inner Ring Width 0.7200 in
Operating Temperature Range -40 to 250 ºF
Dynamic Load Capacity 9800 lbf
Fillet Radius 0.0900 in
Static Load Capacity 12800 lbf
Finish/Coating Uncoated
Manufacturer Product Page Click here
Manufacturer UPC Number 4547359481846
Weight 0.33 lbs

TEMPERATURE RANGE [MIN] -40 °F

MATERIAL Case Carburized Steel
FILLET RADIUS 0.05 in
BEARING TYPE Cone & Cup
WIDTH ACROSS CUPS 0.71
FACTOR 1.80
BORE TYPE Round Bore
TEMPERATURE RANGE [MAX] 250 °F
INNER RING WIDTH 0.72 in
HOUSING SHOULDER DIAMETER - X (MAX) 2.44
NO. OF ROWS 1
INSIDE FILLET RADIUS 0.09 in
DYNAMIC LOAD RATING 9800 lbf
CUP NO. LM29710
LIMITING SPEED - GREASE 5500 rpm
O.D. 2.5625 in
LOAD CENTER -0.17 in
I.D. 1 1/2 in
INCH/METRIC Inch
OIL HOLE w/o Oil Hole
HOUSING SHOULDER DIAMETER - Z (MAX) 2.32
TOLERANCE Class 2
OUTER RING WIDTH 0.55 in
ENCLOSURE Open
STATIC LOAD RATING [MAX] 12800 lbf
CONE NO. LM29749
Bearing Size
LM 29749 NTN Tapered Roller Bearing Cone - 1.5000 in ID, 0.7200 in Cone Width,

Product Picture

LM 29749 NTN Tapered Roller Bearing Cone - 1.5000 in ID, 0.7200 in Cone Width,LM 29749 NTN Tapered Roller Bearing Cone - 1.5000 in ID, 0.7200 in Cone Width,LM 29749 NTN Tapered Roller Bearing Cone - 1.5000 in ID, 0.7200 in Cone Width,LM 29749 NTN Tapered Roller Bearing Cone - 1.5000 in ID, 0.7200 in Cone Width,

Recommended Model

32005-X轴承 FAG S6200-2RSR FAG RTW617 FAG PCJT35-N-FA125 FAG 32232-A-N11CA FAG 22314-E1-K+H2314

FAG CSXF140 FAG 61815-2RSR-Y FAG CSXA045 FAG 3317-M FAG 23236-E1A-M FAG 6010-2RSR

FAG 61820-2RSR-YFAG B71914-C-2RSD-T-P4SFAG B7230-E-T-P4SFAG 22217-E1-K+AHX317FAG GAKR14-PWFAG SL024960 and

other model

We also provide Brand Bearing

If you need, please contact us,Catalog and sample can be offered,let me the model you need,i will quote to you For reference.

TIMKEN,FAG,SKF,INA,NSK,NTN,KOYO,ASAHI,IKO Bearing

Packing , Payment , Delievry and Stock

Packaging
1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
2)Industrial Bearings packaging a)plastic tube + carton + pallet
b). plastic bag +kraft paper + carton + pallet
3)According to the requirement of customers'
Payment
1) T/T:30% deposit, 70% should be paid before shipment.
2) L/C at sight. (high bank charge, not suggest, but acceptable )
3) 100% Western Union in advance. (especially for air shipment or small amount)
Delivery
1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
Stock
1)Availability and supply capacity on a certain basis
