10HL Stainless Steel Beer Making Machine Semi Automatic Control With Jacket
10HL Stainless Steel Beer Making Machine Semi Automatic Control With Jacket
10HL Stainless Steel Beer Making Machine Semi Automatic Control With Jacket
10HL Stainless Steel Beer Making Machine Semi Automatic Control With Jacket
Specifications
Brand Name :
SLET
Model Number :
SL-1000L
Certification :
CE ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD 45,000- 75,000 Per set
Payment Terms :
T/T
Supply Ability :
6 sets per month
Delivery Time :
25 working days after the deposit
Packaging Details :
PE paper & iron frame
Material :
SS304
Heating :
electricity / steam / gas
Control :
Semi-automatic / automatic
Exhausting :
outside / Indoor
Finish :
2B
Insulation :
PU foam, rock wool
Description

10HL Stainless Steel Beer Making Machine semi automatic control with jacket

Product Description

  • 500KG Malt mill

  • 1000l SS304 brewhouse, steam heating suggested

  • Plate heat exchanger

  • Wort aerator

  • 1000L fermentation tanks

  • 1000l brite tank

  • 3000l glycol tank

  • Mobile CIP

  • Control manual control suggested

  • PLC avaiable

10HL Stainless Steel Beer Making Machine Semi Automatic Control With Jacket

Brewery Costs and output

production capacity

100L

200L

300L

500L

1000L

2000L

Floor space

≥15m²

≥25m²

≥35m²

≥50m²

≥80m²

≥120m²

Total power

12kw

12kw

12kw

15/36kw

22/72kw

31/144kw

Consumption of

water(Max)

0.2m³/h

0.4m³/h

0.5m³/h

1.0m³/h

1.5m³/h

2.0m³/h

Total water

consumption per day

0.5m³/h

1.0m³/h

1.5m³/h

2.5m³/h

5.0m³/h

10m³/h

Consumption of malt

20kg

40kg

60kg

100kg

200kg

400kg

Consumption of hops

60g

120g

180g

300g

600g

1.2kg

Yeast

100g/1L

200g/2L

300g/3L

500g/5L

1kg/10L

2kg/20L

Steam

0.017t/hr

0.017t/hr

0.05t/hr

0.10t/hr

0.20t/hr

10HL Stainless Steel Beer Making Machine Semi Automatic Control With Jacket

Beer brewery system
Main components
1.Milling system
Malt mill,grain conveyor,grain hopper
2.Heating system
1.Electric heating
2.Steam heating
3.Burner(Direct fire heating)
3.Beer brewhouse system
1.(Two vessel)Mash/lauter tank,brew kettle/whirlpool tank
2.(Three vessel) Mash tun,Lauter tank,brew kettle/whirlpool tank
3.(Three vessel)Mash/lauter tank,brew kettle,whirlpool tank
4.(Four vessel)Mash tun,lauter tank,brew kettle,whirlpool tank
4.Fermenting system
Beer fermentation tank
Beer bright tank
5.Cooling system
Glycol water tank
Chiller unit
6.Cip cleaning system
Alkali tank
Disinfection tank
7.Control system
Semi auto controller
PLC auto controller
8.Filling system
1.Bottle filling,washing machine
2.Keg filling,washing machine
3.Beer kegs

10HL Stainless Steel Beer Making Machine Semi Automatic Control With Jacket

Our Service

Before-Sales
1. Layout Design for new build brewery
Our experienced engineer( more than ten years) will provide the detailed layout according to your brewery, if needed, we will fly to your brewery at our cost.
2. Exist Brewery Expansion
Expansion of the brew house, beer tanks, or other parts, we will design and manufacture as per your exist brewery.
3. Effective business communication
Our sales team are young and rich of experience, we are full of passion, all of us have been in this business line for more than 8 years, and they are graduated from UK, Russia etc.
4. Brewing consultant
We also bult a good relation with Shandong university and other institutes who are expert in beer brewing, we are capable to provide the most advanced brewing technology.

After-Sales Service
1. Guarantee: 3 years
2. Installation: Our engineers team will provide you the perfect installtion and commissioning service. Almost of them have been to 5 countries even more.
