Characters

i Brew house

• Inner SUS304 Stainless Steel thickness: 3.0mm

• External SUS 304 Stainless Steel thickness: 2.0mm

• Insulation: Polyurethane thickness: 80mm.

• Mash tun, Lauter tun, Boiling Kettle, Whirlpool tun in various combination

• Equipment with tangent tube

• Easy to clean and detachable sparging ball

• 360° CIP spraying ball

• Stream heating, dimplate plate steam jacket thickness: 3mm

• Equipped with: Grain rake and agitator

• Temperature measurement: Temperature Probe PT100

• Food grade centrifugal pump VFD

• Mash infusion process

ii Fermentation tank

• Cone 60° resist compression design,dripping temperature drop

• Carbonation port and stone for special request

• Inner SUS304 Stainless Steel thickness: 3.0mm

• External SUS 304 Stainless Steel thickness:2.0mm

• Insulation: Polyurethane thickness:100mm.

• Dimple plate cooling jacket, thickness:1.5mm

• Dry hopping port

• Stringent tank and Jacket leakage test by water and pressured gas, Tank design pressure is 0.3Mpa

• Temperature display: PT100

• Tri clamp discharge arm with butterfly valve

• 360° CIP spraying ball

Cooling Unit

1. Insulated glycol water tank with or without copper coil for glycol liquid holding and mixing

2. Efficiency chillers or refrigerators with fryon to supply cooling energy

3. Sanitary centrifugal pump for glycol water recycle among tanks and heat exchanger

4. All pipes, fitting, insulation materials are included

Others

Portable CIP system for cleaning the tanks

Steam boiler for brewhouse heating

Water treatment for brew water

Oil free air compressor

Brewery system & Capacity

Jinan Shun Long Service

Before-Sales Service

1. Layout Design for new build brewery

Our experienced engineer( more than ten years) will provide the detailed layout according to your brewery, if needed, we will fly to your brewery at our cost.

2. Exist Brewery Expansion

Expansion of the brew house, beer tanks, or other parts, we will design and manufacture as per your exist brewery.

3. Effective business communication

Our sales team are young and rich of experience, we are full of passion, all of us have been in this business line for more than 8 years, and they are graduated from UK, Russia etc.

4. Brewing consultant

We also bult a good relation with Shandong university and other institutes who are expert in beer brewing, we are capable to provide the most advanced brewing technology.

After-Sales Service

1. Guarantee: 3 years

2. Installation: We shall send 1-2 enginees to your place for installtion and commission work in 20-30 ds.

3. We provide easy damage parts and life long technical support and after sales for free.
