300L Top Manhole Cylindro Conical Fermenter 60 Degree Cone Stainless Steel Material
300L Top Manhole Cylindro Conical Fermenter 60 Degree Cone Stainless Steel Material
300L Top Manhole Cylindro Conical Fermenter 60 Degree Cone Stainless Steel Material
300L Top Manhole Cylindro Conical Fermenter 60 Degree Cone Stainless Steel Material
Specifications
Brand Name :
SLET
Model Number :
SL-300L
Certification :
CE ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD 1750- 2300 Per set
Payment Terms :
T/T
Supply Ability :
30 sets per month
Delivery Time :
25 working days after the deposit
Packaging Details :
PE paper & iron frame
Material :
SS304
Heating :
electricity / steam / gas
Control :
automatic / Semi-automatic
Exhausting :
Indoor or outside
Desigh pressure :
0.5Mpa
Manway :
Side manhole
Description

300L Top Manhole Conical Beer Fermenter

Product Description:

Useful capacity:300L.(+25% head space)

Outline size: φ860*1850 mm.

Inner:SS304.TH=3.0mm Outer:SS304.TH=2.0mm

100% TIG welding with pure argon gas shield

Interior Finish: Overall polishing to 0.4~0.6 μm without dead corner

Insulation: Polyurethane; TH=80mm

Glycol Jacket: Dimpled plate on cone and side

Dished head and 60 degree cone bottom

Top Manhole

Full sanitary sampling valve

Mechanical relief valve 2 bar

Shockproof pressure gauge on CIP arm

SUS304 heavy duty legs with leveling pad and legs support

Thermowell for high accuracy temperature sensor

Fermentation tank pressure:Design pressure 0.5MPa;Working pressure 0.2Mpa.

Fermentation Unit

Standard stainless steel conical cylindrical fermentation tanks

Single size as brewhouse is common used in restaurant

Tanks quantity is exactly calculated by fermentation cycle for various beers

All manhole, valves, pressure gauges, fittings etc are included

300L Top Manhole Cylindro Conical Fermenter 60 Degree Cone Stainless Steel Material

300L Top Manhole Cylindro Conical Fermenter 60 Degree Cone Stainless Steel Material

Other Size & Specification

Capacity Cylinder(ODxH) TOTAL HEIGHT Inner Thickness
3BBL 960x750mm 1880mm 3mm
5BBL 1060x850mm 2250mm 3mm
7BBL 1160 x 900mm 2450mm 3mm
10BBL 1260 x 1150mm 2800mm 3mm
15BBL 1500 x 1220mm 3100mm 3mm
20BBL 1600 x 1400mm 3500mm 3mm
30BBL 1800 x 1650mm 3760mm 3mm
40BBL 1900 x 1850mm 4210mm 3mm
50BBL 1900 x 2050mm 4750mm 3mm
60BBL 2200 x 2150mm 4830mm 4mm
80BBL 2200 x 2900mm 5780mm 4mm
100BBL 2200 x 3600mm 6450mm

4mm

300L Top Manhole Cylindro Conical Fermenter 60 Degree Cone Stainless Steel Material

Related Production:

300L Top Manhole Cylindro Conical Fermenter 60 Degree Cone Stainless Steel Material

After-Sales Service

1. Guarantee: 3 years

2. Installation: Our engineers team will provide you the perfect installtion and commissioning service. Almost of them have been to 5 countries even more.

3. Our appointed agents are in US, Europe, Russia and other ten countries, they will provide you 24 hours service.

300L Top Manhole Cylindro Conical Fermenter 60 Degree Cone Stainless Steel Material

300L Top Manhole Cylindro Conical Fermenter 60 Degree Cone Stainless Steel Material
