Fiber Optic Cable GYTS With Steel Tape Armored Loose Tube Outdoor Cable

Product Overview of Fiber Optic Cable:

Multiple metal stiffeners and yarns are wound around the center tube with appropriate pitch, and a waterproof material is applied at the same time.
Polyethylene sheath or other materials such as low smoke halogen-free polyolefin are tightly coated around the reinforcement.

The Fibers, 200/250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A steel wire, sometimes sheathed with polyethylene (PE) for cable with high fiber count, locates in the center of core as a metallic strength member. Tubes (and fillers) are stranded around the strength member into a compact and circular cable core. An Aluminum Polyethylene Laminate (APL) is applied around the cable core. which is filled with the filling compound to protect it from water ingress. Then the cable core is covered with a thin PE inner sheath. After the PSP is longitudinally applied over the inner sheath, the cable is completed with a PE outer sheath.

Features of Fiber Optic Cable:

• Excellent mechanical and temperature performance guaranteed by the accurate excess Fiber length
• Critical protection to fibers
• The following measures are taken to ensure the water blocking performance
• Single steel wire used as the central strength member
• Special water-blocking filling compound in the loose tube.
• 250μm Colored Fiber
• PBT loose Tube
• Tube Filling Compound(Gel)
• Steel wire central strength member
• PE inner sheath
• Cable filling compound
• PSP(corrugated steel tape) moisture barrier
• PE outer sheath
• Good mechanical and temperature performance
• Steel wire used as the central strength member
• Loose tube filling compound
• 100% cable core filling
• PSP enhancing moisture-proof
• Water-blocking material
• Fiber optical cable complies with Standard YD/T 769-2003.
• Storage/Operating Temperature: -40°C to + 70°C.

Applications of Fiber Optic Cable:

• Adopted to Outdoor distribution
• Suitable for aerial, direct buried pipeline laying installation
• Long distance and local area network communication
• Can be installed conveniently and operated simply.
• Polyethylene sheath makes the cable have good UV resistance
• Product life more than 25 years
• Military Field Wiring
• Construction Site Wiring
• Aerial self supporting
• Outdoor wiring
• Apply to Long distance communication system, Local area network system and Subscriber network system
• Direct Buried Application
• Conduit Application
• Road Wiring
• Snowfield Wiring
• Overhead
• Underground Pipe

Technology Description:

1.

Details of Fiber Optic Cable:

Packaging of Fiber Optic Cable:

FAQ:

Q: Are you trading company or manufacturer ?
A: We are factory

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantit

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.

Q: Do you accept OEM or ODM?
A: Yes,we're factory. any your customized requirements we can do our best to help you realize.
