Tire Cold Conveyor Belt Vulcanized Glue 1 - 1.8 Mpa Curing Pressure
Tire Cold Conveyor Belt Vulcanized Glue 1 - 1.8 Mpa Curing Pressure
Specifications
Place of Origin :
CHINA
Brand Name :
Tongxin
Certification :
IS0
MOQ :
1 Unit/Units
Price :
Negotiable
Packaging Details :
Standard Packing
Delivery Time :
15-30days
Payment Terms :
T/T,L/C,Western Union,Paypal and MoneyGram
Certification: :
ISO CE
Name: :
air cooling conveyor belt vulcanizing press machine
use :
Pressing the vulcanizing machine
Applicable industry :
industry
Temperature adjustment range :
0 ~ 200 ℃
Timing adjustment range :
0 ~ 99 mins
Description

Lightweight water-cooled vulcanizing machine

1 Overview:
DRL type water cooling vulcanizing machine is equipped with water cooling circulation device, the heating plate has a fast cooling speed, and it can be disassembled in 5-10 minutes. Especially in hot weather, high temperature environment and tight construction period, using this water-cooled vulcanizing machine can improve work efficiency and shorten construction period.
JHLHJ water-cooled vulcanization mechanism is light and lightweight, and can be moved manually. Before installation, consider the convenience of power supply and water source. Use a special water pipe to connect the tap water source to the cooling water pipe of the upper and lower heating plates of the vulcanizing machine, but do not put water for the time being. At this time, start the constant temperature to the end of the vulcanization constant temperature time. At this time, turn on the tap water and pass water to the hot plate. When the temperature drops to the process specified value At this time, the equipment can be drained and the vulcanization operation can be completed.

2. Technical parameters:
(1) curing pressure: 1 ~ 1.8 Mpa;
(2) curing temperature: 145 ° C;
(3) Surface temperature difference of vulcanized sheet: ± 5 ℃;
(4) Heating time (normal temperature to 145 ° C): not more than 30 mins;
(5) Power supply voltage: 380V 660V 50 / 60HZ 3PHASES;
(6) Temperature adjustment range: 0 ~ 200 ℃;
(7) Timing adjustment range: 0 ~ 99 mins;
(8) The gap of the upper and lower heating plates after pressing 0.8Mpa is not more than 0.4mm.
