Portable Animal Ultrasound Veterinary Full Digital B Mode For Cow Horse Donkey Big Animal

Animal Ultrasound Advantages:

Full Digital B Mode Imaging

The B-mode (brightness mode) is a standard imaging mode used in ultrasound, providing clear, two-dimensional images of internal structures. The digital feature ensures that images are captured in high resolution, allowing for detailed and accurate visualizations of tissues, organs, and other structures. This is crucial for diagnosing conditions in large animals such as pregnancy, internal injuries, or organ abnormalities.

Portability

This ultrasound system is designed to be compact and portable, making it ideal for use in field conditions or on-the-go diagnostics. Veterinarians can easily transport the device between farms, stables, or rural locations, ensuring they can perform ultrasounds in areas where stationary machines might not be accessible.

Large Animal Focus

Tailored specifically for large animals, this ultrasound is powerful enough to handle the requirements of cows, horses, donkeys, and other large livestock. It offers a larger screen and probes with deeper penetration to accommodate the size and depth of these animals' bodies, ensuring that veterinarians can obtain accurate images for health assessments, pregnancy checks, and more.

Animal Ultrasound Standard

Animal Ultrasound Optional:

Animal Ultrasound Application:

BT-VUD67 can be widely used in normal ultrasound diagnosis like abdomen and pregnancy.

Main market: big animals’ pregnancy check and follicular aspiration (Bovine, equine, ovine, canine, feline, goat, swine and llama).

Animal Ultrasound Feature:

• 1kg weight. Smart and light.
• High-capacity lithium Battery, more than 6 hours work.
• Sunshine cover, suitable for use in outdoor strong sunshine.
• Available for left/right hand alternative use, eliminating operate fatigue.
• Multiple use method: hand-held, chest hanging, back hanging, waist hanging, ect.
• Optional professional ultrasound goggles, convenient for outdoor use, meet different need.
• Have soft rubber coat, splash-proof, dust-proof.
• 2 kinds filter function, 7 kinds compress curve, 100 frames image permanent storage, 256 frames cine loop, Automatically calculate the Back fat and Lean percentage of swine.

Animal Ultrasound Tech Specification

--- Adopt 5.7” high resolution LED display, with High brightness, high contrast, wide viewing angle, suitable for outdoor use

--- English language

--- Single probe socket, auto identify probe

--- Body mark:1.General 2. Bovine 3.Canine 4.Equine 5.Feline 6.Cardio 7. Swine, total 27 kinds

body mark with probe director

--- Display mode:B,2B,4B ,B/M,M

--- Gain:0～127dB

--- Contrast:27～90dB

--- Gray:256

--- Focus: 1,2,3,4

--- Magnification:0.8,1.0,1.2,1.5,1.6,2.0,2.4,3.0

--- Multi frequency:4 different frequencies of each probe

--- Depth: 8 steps, 240mm,

--- Frame correlation:0,1,2,3

--- IP:0,1,2,3

--- IE:0,1,2,3

--- Character brightness:select between160,192,224,255

--- Key sound: on/off

--- Compressing curve:7 kinds

Animal Ultrasound FUNCTIONS:

--- Local zooming

--- Depth hoist

--- Image up/down, left/right, black/white

--- Pseudo color: 8 kinds

--- Four different angles / switchable width ；

--- 100 frames permanent storage

--- Cine loop:256 frames

--- Puncture guide, with two approvable guiding lines whose angle and position can be adjustable.

--- The gravel software package with real-time position line measurement

--- Normal measurement: Distance, circumference, area (trochoid or ellipse), volume, etc.

--- Cardio measurement:Depth, slope, heart rate, cycle；

--- OB measurement:Cattle, dogs, horses, pig, cats, goats, camels and sheep and pre-gestational age birth

--- Back-fat and lean automatic calculation function；

--- OB Report；

--- USB port for large capacity storage ( file management, software upgrade, one-key storage),and laser color printer to print image & report；

--- With green energy-saving function

--- Grid measurement:6 different(none,point grid,line grid, 10mm point ruler, 2mm point ruler, 10mm&2mm point ruler)

--- Video output:ＰＡＬ/ＮＴＳＣ

--- Power supply:AC110/230 -15％～＋10％, 60/50Hz±1Hz；

--- Battery:large capacity(5200MAh) battery 1PC, more than 6 hours work

--- N.W.:1.1kg；

--- Dimension:212×154×58mm(L×W×H)
