CE Approved Can Packaging Machine Automatic Palletizer Machine 380V 3P
CE Approved Can Packaging Machine Automatic Palletizer Machine 380V 3P
CE Approved Can Packaging Machine Automatic Palletizer Machine 380V 3P
CE Approved Can Packaging Machine Automatic Palletizer Machine 380V 3P
CE Approved Can Packaging Machine Automatic Palletizer Machine 380V 3P
CE Approved Can Packaging Machine Automatic Palletizer Machine 380V 3P
CE Approved Can Packaging Machine Automatic Palletizer Machine 380V 3P
CE Approved Can Packaging Machine Automatic Palletizer Machine 380V 3P
Specifications
Brand Name :
PEIYU
Model Number :
SPC
Certification :
CE&ISO
Place of Origin :
Shanghai,China
MOQ :
Negotiate
Price :
Negotiate
Payment Terms :
L/C, T/T
Delivery Time :
40 working days
Packaging Details :
wooden case
Packaging Type :
Cartons, Cans, Bottles, Bags, Case
Power :
11kw
Voltage :
380V 3P
Driven Type :
Electric
Weight :
8000kg
Dimension(L*W*H) :
L8400MM*W4700MM*H3700MM
Description

CE Approved Can Packaging Machine Automatic Palletizer Machine 380V 3P

Palletizer is a machine which can arrange the cartons which has been loaded containers in a certain code on the tray. The stacking is automatic and launched many layers. Stacking complete, the layers will be push out. It is easy for the forklift to convey the layers to storage facility. This machine uses PLC+touch screen controls, intelligent operation management, simple, easy to master, can also greatly reduce the number of workers and labor intensity.
1) Form: Low stacking-type
2) Product capacity: 15 cartons/min(specific number related to the number of carton of each layer, 2 layers per minute)

Product Description

Glass Bottle Mechanical Palletizer (Low Level Palletizer )
1) CE certificate
2) ISO9000: 2000 Certificate
3) Volume: 0.25-2.5L
4) Can, glass bottle
5) Automatic system
6) High efficiency, easy maintenance



Main features


1) Adopt touch-screen operation to achieve human-computer dialogue. The rate of products can be showed. The cause and location of the failure can also be showed. High level of automation is adopted. Sorting stacking layers of cartons, pallet supply and discharge can be controlled by the programmable PLC.
2) Using Siemens PLC and Touch-screen (10 inches)
3) Security doors, hood with electrical sensors, when the hood opens, the machine will stop working to protect the workers.
4) It is easy and convenient to adjust the mode of stacking with the touch-screen.
5) The mode of stacking is stable and efficient and will reduce a lot of manpower.
6) Carton supply system uses brake motor control, ensure the carton conveyor
7) Large stack storage, with 12-15 stacks, which can achieve automatic stack supply.
8) Low noise, according to international standard below75dB
9) No need to change the stack part, which can achieve several stacking way
10) Electricity consumption: AC, 3phase, 380V, 9KW 50Hz
11) Air consumption: 500NL/MIN(5-6kg/cm2)
12) Size (L) 7, 200mm× (W)4, 000mm× (H)3, 300mm
13) Weight: 6000kg
