High Performance Shrink Sleeve Equipment Touch Screen Control Two Sides Seal
High Performance Shrink Sleeve Equipment Touch Screen Control Two Sides Seal
High Performance Shrink Sleeve Equipment Touch Screen Control Two Sides Seal
High Performance Shrink Sleeve Equipment Touch Screen Control Two Sides Seal
High Performance Shrink Sleeve Equipment Touch Screen Control Two Sides Seal
High Performance Shrink Sleeve Equipment Touch Screen Control Two Sides Seal
High Performance Shrink Sleeve Equipment Touch Screen Control Two Sides Seal
High Performance Shrink Sleeve Equipment Touch Screen Control Two Sides Seal
Specifications
Brand Name :
SPC
Model Number :
SPC-2500
Certification :
CE
Place of Origin :
Shanghai,China
MOQ :
Negotiate
Price :
Negotiate
Payment Terms :
L/C, T/T
Delivery Time :
within 30 days
Packaging Details :
wooden cases
Type :
Wrapping Machine
Application :
Machinery & Hardware
Driven Type :
Electric
Power :
20KW
Feature :
Electric Shrinking Machine
Condition :
New
Description

High Performance Shrink Sleeve Equipment Touch Screen Control Two Sides Seal

Characteristic:


1. The film covering and sealing device adopt advanced heat sealing and heat cutting structure, with advantages of sealing firmly, neat edge and good joined performance.
2. The sealing and cutting part drived by cylinder, with guide columns at both ends, which can guarantee the process steadily and steadily.
3. Special protection function: when obstruction on the sealing and cutting position, the equipment will be prevent and alarming at the same time to protect the package from damaged.
4. Feeding trough adopts flat feeding type.
5. The heating part adopts high-quality stainless steel cooling fin, with advantage of steady & homogeneous heat dissipation and long use life.
6. PID temperature controller: accurate and energy-saving.
7. The whole equipment controlled by automatic controller, with steady and reliable production, can apply to working long hours and non-stop.


Main electric fittings:


1. Choosing generic brand components, unify specification can be random exchange.
2. Using PLC programmable control system which guarantee exact and steady packaging process.
3. The shrinking part adopts Sino-German Bader motor, the feeding speed can be adjustable to achieve the good packaging effect.
4. Touch screen control, make the equipment into the high-precision intelligent state. All movements are subject to monitoring, all alarm and PC state will displayed on the touch screen, which make the equipment more safe and reliable.
5. Pneumatic component adopts import brands.

Main Technological Data:

Name: Automatic heat shrink film packaging machine (trade edition)
The thickness of shrink film: 0.03-0.10mm (Can be designed as your special requirements)
The film’s max width: 600mm
Shrinkable bake temperature: Can be arbitrary adjustable within room temperature~200℃
The max packing speed: 8-10 packs/min (According bottle-type)
Power supply: 380V/220V 50Hz three-phase five-line
Power: About 20kW
Working air pressure: Dry air ≥0.6MPa
Air consumption: 25m3/h
Packaging type: Two sides open, two sides seal
Shrink film: PE, POF, PV etc.
Suitable bottle-type: Glass bottle, pop can, PET bottle and other material which 200 ℃ temperature-resistant
Weight: 1500kg

Pre-sale service

1. Providing professional technical support.

2. Send the product catalog and instruction manual.
3. If you have any question PLS contact us online or send us email, we promise we will give you a reply at the first time!
4. Personal call or visit are warmly welcome..

Sale of service

1. We promise honest and fair, it's our pleasure to serve you as your purchasing consultant.

2. We guarantee punctuality, quality and quantities strictly implement the terms of contract.
3. Focus on providing you One-Step solution for your requirements.

After sale service

1. Where to buy our products for 1 years warranty and life long maintenance.
2. 24-hours telephone service.
3. A large stock of components and parts, easily-worn parts.
4. Door to door technical support
