High Speed Automated Conveyor Systems Air Feeding Conveyor In Production Lines
High Speed Automated Conveyor Systems Air Feeding Conveyor In Production Lines
High Speed Automated Conveyor Systems Air Feeding Conveyor In Production Lines
High Speed Automated Conveyor Systems Air Feeding Conveyor In Production Lines
High Speed Automated Conveyor Systems Air Feeding Conveyor In Production Lines
High Speed Automated Conveyor Systems Air Feeding Conveyor In Production Lines
Specifications
Brand Name :
PEIYU
Model Number :
SPC
Certification :
CE&ISO
Place of Origin :
Shanghai,China
MOQ :
Negotiate
Price :
Negotiate
Payment Terms :
L/C, T/T
Delivery Time :
within 25 days after received L/C or T/T
Packaging Details :
wooden standard
Application :
Food,beverage,chemical,medical
Voltage :
220V/380V/440V
Frame material :
Stainless steel
Speed :
10-20m/min(adjustable)
Driven type :
Electric
Packing type :
Cartons,cans,bottle,stand-up pouch,case,
Description
High Speed Automated Conveyor Systems Air Feeding Conveyor In Production Lines
Product Description

Air conveyor system stand on the ground by foot support, fans should be installed above the air conveyor. There equipped with air primary filter at the entrance of each fans to avoid dust blow into bottle. Bottle neck in the air conveyor was stuck by the hanging bottle board then delivery to the filling machine by wind.


Main features


1, In addition to fans, legs, hanging bottle board and other plastic, nylon, and the rest are made of 304 stainless steel.
2. Out of the clean room there equipped with air primary filter at the entrance of each fans to avoid dust blow into the bottle, inside the clean room there equipped with medium filter guarantee the air in the filling area is clean, so that prevent second pollute in the filling area.
3, Between the fan and the box body is equipped with the manual air quantity adjustment device, the control air quantity, guarantees the bottle conveying works smoothly.


Main technical parameter

Item Parameter
Air conveyor section size 180×180mm
Air conveyor height 1300mm(between the bottle hanging board and ground)
Thickness of steel plate 2mm SS304
Blowing rate >3400m³/h
Filter structure Plate structure
Filter material Galvanized steel frame,Stainless steel mesh
Filter specification 610×610×102mm
Bottle volume 200-3000ml
Bottle diameter 50-120mm
Air conveyor angle <15°
Initial resistance <55Pa,final resistance is 4-5 times as initial resistance
Air conveyor length 3M(can add)

Company Information


New branch-Anhui Peiyu Packing Technology Co.,Ltd ,located at NO.2588 East Qingliu Road,Suchu Modern Industrial Park,Chuzhou Anhui Province

Our Services

Installation and commissioning

We'll send experienced technicians after the equipments arrived buyer's workshop . Our technicians 'll guide the installation and commissioning to fulfill designed capability within designed time . The seller will also offer training including:equipment structure and maintenance,machine control and operation etc .

After-sales service

The guarantee period will be 1 year after qualifying the equipment .After guarantee period , we'll provide technical support and after-sales service for life.
