Adjustable Automatic Stretch Wrap Machine With Hydraulic Jack OEM​

1.Application Scenario for Stretch Wrap Machine,stretch wrapping machine,Stretch Wrappers:

The Stretch Wrap Machine,stretch wrapping machine,Stretch Wrappers is widely used in water production line, beverage production line, canned food production line, pet food production line, beer production line, liquid seasoning production line, etc.

2. Equipment Overview for Stretch Wrap Machine,stretch wrapping machine,Stretch Wrappers:
The Stretch Wrap Machine,stretch wrapping machine,Stretch Wrappers is a special equipment that automatically wraps the stretch film around the pallet goods. It plays a role in dust-proof, moisture-proof and bulk-proof packaging for the goods, thereby protecting the products, saving packaging costs, reducing the labor intensity of workers and improving the packaging effect.
The pallet goods are placed on the conveyor line, and the pallet goods transported upstream are transported to the packaging machine station through the conveyor line.

According to the set packaging parameters, the packaging machine is automatically started, the film is automatically applied, and the continuous packaging process is realized. After the wrapping is completed, the film is automatically cut. It is transported out of the packaging station to the next section of the conveyor line. The next goods cycle packaging begins.
Use: The pallet products that have been palletized are wrapped and packaged by rotary stretch film.

3. Equipment Features for Stretch Wrap Machine,stretch wrapping machine,Stretch Wrappers:
1) The whole machine adopts PLC programmable controller and human-machine interface display control system to realize the integration of machine, electricity and gas, and has manual/automatic optional functions.
2) It is equipped with a photoelectric switch to automatically sense the height of the wrapped goods.
3) The equipment cantilever rotates around the product, and the product is stationary, which can realize automatic film wrapping, greatly reducing the transition connection between equipment and ensuring the safety of pallet products.
4) Equipped with hydraulic lifting mechanism to realize film winding on the bottom pallet of the stack.
5) The turntable of the equipment is equipped with a high-sensitivity emergency stop system controlled by a safety photoelectric detector.
6) The film release system adopts a double chain mechanism, which is stable and reliable, and the rising and falling speeds are variable frequency speed regulation. The number of layers wrapped on the upper and bottom of the wrapped objects is controlled separately.
7) The equipment is equipped with automatic film loading and film cutting devices to realize fully automatic film loading and cutting. The film rack film discharge system uses a separate pre-stretching motor, which allows the pre-stretched wrapping film used by the market standard machine to be stretched 2.5-2.8 times, which can effectively save consumables costs.
8) The equipment is equipped with a fault alarm light. If a fault occurs during production, the alarm will automatically stop.

4. Technical parameters for Stretch Wrap Machine,stretch wrapping machine,Stretch Wrappers:
a. Cargo specifications: L1200 * W1200 * H1800mm Max (including pallet height 120mm)
b. Conveyor table height 650mm,
c. Effective packaging height: 1800mm, minimum winding height 90mm above the roller conveyor surface (subject to actual conditions), with hydraulic lifting, all pallets can be wrapped.
d. Cargo weight: 1000kg Max
e. Packaging efficiency: 15-25 pallets/hour
f. Conveying method: roller conveyor (customer-matched)
g. Machine color: company standard color.
h. Rotary arm speed: 3-15 rpm (adjustable speed)
i. Film rack type: pre-stretched film rack, stretch ratio 250% adjustable film tension
j. Fully automatic film loading, film cutting, and film brushing mechanism
k. Stretch film: thickness 15-20um, width 500mm, inner core ∮76mm; 15KG/roll
l. Film cutting method:
m. Wrapping machine: thermal fuse
n. Top film: rodless cylinder + blade
o. Air source: 0.4-0.6Mpa
Power supply: 3-phase 5-wire AC 380V/50Hz
Total power: 3.8KW

5. Main configuration for Stretch Wrap Machine,stretch wrapping machine,Stretch Wrappers:

6.Quotation and delivery time for Stretch Wrap Machine,stretch wrapping machine,Stretch Wrappers:

(1). Quotation validity period: 1 month;
(2). Payment method: T/T, L/C.
(3). Customers provide the product and packaging samples required for factory trial free of charge;
(4). Delivery time: 60 working days from the receipt of customer deposit and product packaging samples.

7. Quality Assurance for Stretch Wrap Machine,stretch wrapping machine,Stretch Wrappers:

(1). The company guarantees that the goods provided are brand new, unused, made of the latest design and suitable materials, and meet the quality, specifications and performance specified in the technical contract in all aspects;
(2). The company guarantees that after the production line is properly guided, installed and debugged, the equipment will reach the various technical performance indicators of the product within 15 days of the entire system being put into operation;
(3). The company guarantees that within the quality assurance period specified in the contract, it will be responsible for defects, failures and damages of the production line caused by defects in the design, process, manufacturing, installation, debugging or materials provided and the quality of the seller's equipment;
(4). The equipment quality assurance period is 12 months after the acceptance of the production line. If during the quality assurance period, it is found that the quality or specifications of the equipment do not meet the contract provisions, or it is proved that the equipment is defective (including potential defects or the use of unqualified materials, etc.), the buyer has the right to propose rectification to the seller within the product quality assurance period according to the inspection certificate issued by the statutory department;
(5). The company guarantees the mechanical properties of the equipment provided, the quality of the product and the consumption indicators of the product.

8. Equipment warranty for Stretch Wrap Machine,stretch wrapping machine,Stretch Wrappers:

(1). After the equipment is accepted, a 12-month warranty is provided, and the control system (standard Huichuan brand) provides a 24-month warranty; during the warranty period, our company will provide users with free spare parts and timely and effective services (wearing parts are not covered by the warranty);
(2). If the equipment fails and needs to be repaired on site, our company guarantees that the maintenance personnel will rush to the customer's site within 48 hours to help the customer eliminate the fault in time (except for force majeure);
(3). After the warranty period, our company will provide users with a wide range of preferential technical support, sufficient spare parts supply and other after-sales services for life;

9. Packaging and transportation for Stretch Wrap Machine,stretch wrapping machine,Stretch Wrappers:
(1). Packaging method:
The packaging uses new and sturdy special packaging boxes or fixed frames, which are suitable for long-distance transportation, moisture-proof, rust-proof, shock-proof, suitable for land transportation, sea transportation and overall lifting.
(2). Transportation method: land transportation, sea transportation.
