860m3/H Municipal MBBR Based Sewage Treatment Plant Moving Bed Biofilm Reactor Technology
860m3/H Municipal MBBR Based Sewage Treatment Plant Moving Bed Biofilm Reactor Technology
860m3/H Municipal MBBR Based Sewage Treatment Plant Moving Bed Biofilm Reactor Technology
860m3/H Municipal MBBR Based Sewage Treatment Plant Moving Bed Biofilm Reactor Technology
860m3/H Municipal MBBR Based Sewage Treatment Plant Moving Bed Biofilm Reactor Technology
860m3/H Municipal MBBR Based Sewage Treatment Plant Moving Bed Biofilm Reactor Technology
Specifications
Brand Name :
Biocell
Model Number :
MP-1
Certification :
ISO9001
Place of Origin :
Wuxi China
MOQ :
1 unit
Price :
$21,804-$223,587
Payment Terms :
T/T, L/C
Supply Ability :
50 units per month
Delivery Time :
45-60 days (to be negotiated)
Packaging Details :
containerized package
Flow :
25m3/d
Tank Size :
6m*2.4m*2.4m(L*W*H)
Shipping WT. :
5500kg
Installed Power :
1.5kw
Description

Package Mbbr Technology Wastewater Treatment Plant

Case study Municipal Wastewater

Start Up May 2016

Capacity 20000 m3/d

Location Iran

Challenge

This is the first large water reuse project in Iran, the first project which use the waste water as steel production water source, the whole water supply system of the factory not need to use any fresh water. We cooperated with , and provide the MBBR process package and technology service.

This WWT plant design capacity is 860 m3/h, it is the municipal waste water, the Inlet and MBBR outlet values as follows:

Parameter Unit Inlet values Outlet values
COD mg/L 80~250 <50
BOD5 mg/L 40~150 <10
NH4-N mg/l 0.1~50 <5

Solution

The treatment process is MBBR+UF+RO, and provide a new solution for the severe water shortage problem in Iran.

The main characteristic of Moving Bed Biological Reactor (MBBR) configurations is that there is no sludge recycle from a secondary clarifier. MBBR is essentially a simple, once-through process, where all of the biological activity takes place on the biomass carriers.

860m3/H Municipal MBBR Based Sewage Treatment Plant Moving Bed Biofilm Reactor Technology
