Biomass Wood Pellet Mill Machine 420 Ring Die Wood Sawdust Press

Biomass fuel is a renewable new energy. It has a huge economic and environmental benefits. Make full use of biomass energy can not only solve the problem of scarcity of resources today, but also to protect the Earth's environment. Then the wood pellet mill machine is the main machine to produce biofuel equipment .

Raw material for wood pellet mill machine :

Although many kinds of raw materials (such as household garbage and waste) are suitable for making biomass pellets, only two kinds of them, agricultural wastes and wood residues, are frequently applied.
Agricultural wastes: wheat straw, rice husk, corncob, corn stalk, tea leaf waste, peanut shell, leaf mustard, sunflower seed shell, jute waste, coffee bean pulp, waste cigarette stem, palm kernel shell, bagasse, bean stalk, coconut shells, dry grass, etc.
Wood residues: wood shavings, sawdust, and little bark left behind in sawmill, furniture factory, paper plant and construction industry; branches and rotten wood lying by roadside; dead trees killed by insects or diseases

1.the working principle : the flat die wood pellet mill its main working principle is that the motor is driven by high-precision gears to drive the ring die to rotate at high speed. Two eccentric pressure roller assemblies (extrusion cylinders) are arranged inside, and the material enters the granulation chamber ,is physically extruded into a diameter of 6-8- 10-12mm pellets .

2.The advantage :High-quality bearings are used in the transmission part of the whole machine to ensure high-efficiency, stable and low-noise transmission. The ring die adopts the quick-discharge hoop type, and the feeding adopts the stainless steel fan blade for forced feeding to ensure uniform feeding, The motor and the gear box are connected by an international advanced level compensation type serpentine spring coupling, which is fed with variable frequency speed regulation to ensure uniform feeding.

1. Technical Parameters

Remarks

◆ The above capacity comes from 8mm biomass pellets production.

◆ The final capacity of Pellet Mill depends on the features of raw materials, operation and maintenance,etc.

◆ There are 2 rollers in the pressing chamber.

Except 1-1.5t.h wood pellet mill machine :

Main Power : 90kw, 110kw, 132kw,200kw

Capacity : 1-3 tons/hour

Application : Medium to large-scale pellet production.

4The wearing parts of wood sawdust pellet mill machine:When the material go into the chamber ,it is squeezed by ring die and roller shell ,so this two parts are easy to be worn .For different material such as soft wood and hard wood ,it would result in different degree wearing ,and the cleanliness of material like if iron stuff is inside or not ,the moisture etc. all will influence using time of ring die and roller shell .

5.Factory introduction :Our factory was founded 2003, which was the earliest manufacturer of biomass pelletizing machines in China. Since then we has only produced biomass pelleting and related machines, wear parts for the entire pelletizing technology and plant. It is located in HuqiaoTown, ,Liyang City, Jiangsu. Its core business includes design, manufacture,installation, assembly, training, accessories, and after-sales servicof machinery and production lines used in biomass pellet industry. Well over 400 plants and machines from our factory have since enjoyed success with continuous use domestic an worldwide, including:

Vietnam, Thailand, Malaysia, Indonesia, Russia, Bulgaria, Serbia, England, Greece, Chile,

Mexico, Australia, etc.

Why choose us :

Profession and Duty :

1. large CNC die drilling center

2. Pellet mill machine assembly and testing center

3. Large embryo forging base

4. Auxiliary manufacturing base and pellet production test center
