Laboratory Vacuum Emulsification Reactor Medical Laboratory Equipment
Laboratory Vacuum Emulsification Reactor Medical Laboratory Equipment
Laboratory Vacuum Emulsification Reactor Medical Laboratory Equipment
Laboratory Vacuum Emulsification Reactor Medical Laboratory Equipment
Specifications
Brand Name :
HUXI
Model Number :
HR-2L
Certification :
CE,ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100
Delivery Time :
7-15 days
Packaging Details :
Carton
Model :
HR-2L
Item no :
1011018002001
Power Supply :
220V 50/60HZ
Max mixing capacity(ml) :
500-2000
Max emulsification(ml) :
1000-2000
Working Temperature(℃) :
170
Reach vacuum :
-0.097---0.02mpa
Viscosity :
100000mpas
Mixing Speed Range :
0-230rpm
Propeller :
Anchor type ribbon scraping wall stirring slurry
Description

Laboratory Vacuum Emulsification Reactor Medical Laboratory Equipment

Laboratory Vacuum Emulsification Reactor

Application:


Laboratory vacuum emulsification reactor: realize the process of material dispersion, emulsification, homogenization and mixing under vacuum or pressure environment. It can be equipped with a variety of high-viscosity stirrers, high-shear homogenizers, and reliable vacuum sealing systems and temperature control systems. Various sensing and detection systems can simulate industrial production in a laboratory environment. At present, the laboratory processing capacity is: 1L, 2L and other series. It is used for dispersion, mixing, emulsification, homogenization, stirring and dissolving in the laboratory. The whole reaction process of stirring, homogenizing, emulsifying, dispersing, mixing, etc. of the material can be observed through a glass kettle under vacuum or pressure conditions, and it can also be homogeneously emulsified and dispersed by stainless steel pressure and high temperature.

Main features:

● Production of cheeses, lotions, lotions and preparations of fats in the pharmaceutical and cosmetic industries;

● Mix solids such as calcium carbonate, talc, titanium oxide, etc. with the emulsion;

● High shear dispersion emulsification or polymer polymerization reaction stirring in lithium battery industry;

● Grinding and dispersing solids and fibers in liquids and polymers. Such as glue strong vacuum stirring;

● It can measure the temperature, pressure, viscosity, PH, etc. of materials at the same time. The material can also be heated or cooled.

Technical Parameters:
Model HR-2L
Item no 1018002001
Power Supply 220V 50/60HZ
Max mixing capacity(ml) 500-2000
Max emulsification(ml) 1000-2000
Working Temperature(℃) 170
Reach vacuum -0.097---0.02mpa
Viscosity 100000mpas
Mixing Speed Range 0-230rpm
Propeller Anchor type ribbon scraping wall stirring slurry
Scraper Material Silicone Rubber
Homogenizer motor power 1050W
Homogenizer speed 7500-30000rpm
Working head 25DG
Reactor lid opening Homogenizer port + hopper port + temperature measuring port + vacuum port + 3 spare ports
Lifting bracket distance 350mm
Sample touch material SS316L,borosilicate glass,FKM10
Outer diameter of vacuum port 10mm
Outer diameter of inlet and outlet of glass kettle jacket 12mm
Allowable ambient temperature(℃) 5-40
Allowable ambient Humidity(%) 80
Exterior Dimension(mm) 400*390*780
Standard weight(kg) 38
