SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine
SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine
SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine
SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine
SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine
SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine
SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine
SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine
Specifications
Brand Name :
SKYWIN
Model Number :
SK-380S
Certification :
CE
Place of Origin :
Guangdong, China
MOQ :
1 set
Price :
EXW price 5,500 USD
Payment Terms :
L/C, T/T
Supply Ability :
1 set / 45 days
Delivery Time :
10 work days
Packaging Details :
Wooden case for biscuit machine suitable seaworthy.
Type :
Multi-Function Packaging Machine
Packaging Type :
Bags, Belt, Pouch
Applicable Industries :
Hotels, Food & Beverage Factor
Condition :
New
Automatic Grade :
Automatic
Warranty :
1 Year
Marketing Type :
Ordinary Product
Core Components :
Motor, PLC, Gear, Bearing
Material :
304 Stainless Steel Material
Phase :
Single
Control system :
PLC control
Packaging Material :
plastic, Paper,
Function :
FILLING, Wrapping, Sealing
Application :
Food
Machine weight :
650KG
Packing speed :
250-300bags/min
Usage :
A date printer
Description
2021 Super September Promotion
Reduce the price, without reducing the quality!

SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine

3 Servo Motors; Painted steel cover; Schneider Switches; PLC control system; High Speed Flow Packing Machine; conveyor length 2.4m

SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine

Product Details

SK-380S

flow pack packaging machine
  • 3 SERVOS---1.FILM&END SEALER/2.CENTER SEALER/3.CONVEYOER
  • One ink type date printer
  • Standard conveyor belt length 2540mm, side plate support.
  • Photo sensor
  • With Middle plastic brush or stainless steel belt.
  • Packing speed: 250-300bag/min (Subject to material and thickness of film and packaging type)
  • Bag size:Length 80-500mm, Width 60-150mm, Height 5-45mm
  • Max outer diameter < 300 mm
  • Max width of the packing film: 380mm
  • Max width of the packing film: 380mm
  • Packing film thickness: 0.03-0.07mm
  • Total power consumption: 5.6KW / Single 220VAC/50Hz
  • Machine Size: 4200 x 950 x 1650mm (L x W x H)
  • Food contact part 304 Stainless Steel
  • Machine weight: 650 kg

SK-530S

flow pack packaging machine
  • 304 Stainless steel cover&Structure.
  • 3 Delta Servo Motors
  • Schneider Switches
  • PLC control system
  • Upper and Down Knife Jaw Temperature separate control
  • Feeding roller without temperature control
  • Heating rollers&Heating plate with temperature control
  • Sealing rollers single temperature control.
  • Film width 370mm
  • included Ink date printer
  • Speed: 30 to 350 packs/minute
  • Bag size:
  • Length 80-500mm(Adjustable by screen), Width 35-160mm, Height 5-55mm
  • Max outer diameter < 300 mm,
  • Max width of the packing film: 380mm,
  • Packing film thickness: 0.04-0.07mm
  • Machine dimension: (L x W x H): 4000 x 950mm x 1650mm
  • Power consumption: Single phase: 220V/50Hz
  • Total Power 6kw
  • Heating power 3.5kw
  • End seal servo 1kw,film servo 0.75kw,Conveyor servo 0.4kw
  • Gross weight: 450kg
  • Packing materials:OPP/PE/PVC/CPP/PTPE/KOP/CPP/ALUMINUM FILM.Conveyor feeding belt for the Flow packing machine

SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine

SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine

SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing MachineSK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine

SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine

Packing Sample

SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine

SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine

More details, Please contect with us!!!

SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine

Packing&Shipping

SK-380S 3 Servo Automatic Controlled Flow Pillow Biscuit Packing Machine

Welcome to contect me!
