Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line
Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line
Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line
Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line
Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line
Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line
Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line
Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line
Specifications
Brand Name :
skyiwnbake
Model Number :
two
Certification :
ce, iso900
Place of Origin :
gungdong , China
MOQ :
one set
Price :
12000 usd/set
Payment Terms :
L/C, T/T
Supply Ability :
100 set/month
Delivery Time :
30 days
Packaging Details :
woodern box
Application: :
Biscuit
Biscuit :
300-1200pcs/min
Voltage :
2220-380V/50Hz
Output product name: :
biscuit sandwich machine
After-sales Service Provided: :
Free spare parts, Engineers available to service machinery oversea
Material: :
304 Stainless Steel
Power: :
12kw
Machinery Test Report :
Provided
Main motor: :
TAIDA servo motor
Warranty :
1 year
Touch screen :
SIEMENS PLC
Description

Skywin Biscuit Cream Sandwich Biscuit Machine connect sk 380 flow packing machine

This machine is suitable for chocolate, cream and Jam flavor biscuit sandwiching and flow packing.

capacity from 500~1200pc/minute sandwiched biscuit.

Product Description

Application

Sandwich biscuit machine can make one color 2+1,3+2 sandwich bisucit with cream ,jam ,chocolate and so on .

We can make single row ,two rows ,four rows ,six rows ,high speed sandwich biscuit machine by advance structure&design

Just according to customer special requirement .

Advanced Technology

Technical Parameter:

 Single Lane Sandwiching Machine Two Lane Sandwiching Machine
biscuit size Square Rectangle
L(35-70)x W(30-60)x H(3-8)mm L (35-80) x W(40-65)mm
Round Round

Φ35-70mm

thickness:3-8mm

Φ35-Φ65mm

thickness:4-8mm
Capacity

100-600

sandwiches/min

600-1200

sandwiches/min
operating voltage single-phase AC 220V 50Hz single-phase AC 220V 50Hz
machine size 7000x1900x1470mm 7430x3300x1500mm

Weight(Cream tanks

capacity )

 1120kgs (40L) 1350kgs (50L)
total power 4Kw 4Kw

Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line

Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line

  • SKYWIN Food Machinery Group Company was Founded in 2010,which is lotated in Beijiao, Shunde, Foshan, Guangdong, CHINA
  • Foshan City is stainless steel Birthplace.
  • Skywin Group has two factories, One is for Large Biscuit & Cookies & Wafer Production Line, One is for Automatic Biscuit Sandwiching Machine with Packing System.
  • We have more than 60 professional staffs to match delivery time, base on “International Quality, Competitive Price”.
  • We insist on:

Premium Quality Standards

High Value for Money

Lasting Partnership

Technical Monopoly Protect

After Sales Dependability

We have three connection options:

1. Sandwich biscuit machine connected packing machine (with pillow packing or trayless on edge packing)
2. Sandwich biscuit machine connected with star wheel stacker
3. Sandwich biscuit machine connected with multiplier

Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line
Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line

Main Features:
(1). PLC for simple operation including machine set-up, hopper controls, speed adjustments
(2). Removable scrap trays are provided for simple scrap collection and machine cleaning
(3). Easy to operate: Simple adjustments for machine speeds, cream volume
(4). Sanitary design with stainless steel for food contact parts, including cream stencil and interchange faster
(5). Separating cream holding tank and feeding system
(6). The pusher with double chain assure machine running stable and cleaning and maintenance
(7).Every cream hopper with independent motor and reducer
(8).Mobile cream hopper can cleaning while finish working separately
(9)SUS304 stainless gear pump, connection tubes between cream hopper and stencil are jacket design.
(10) Temperature metering device installed the cream stencil and convenient change-over stencil design for different cream shapes

Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line

Sandwich biscuit machine with multiplier

Automatic Cream Jam Filling Biscuit Sandwich Machine For Biscuit Production Line

Sandwich biscuit machine with trayless on edge packing
