Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion
Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion
Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion
Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion
Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion
Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion
Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion
Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion
Specifications
Brand Name :
junqi
Model Number :
OWB-1412-130
Certification :
CE,Rohs
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1000 pcs per day
Delivery Time :
5-30days
Packaging Details :
Carton+packing foams
Product Name :
BLDC Blower
Rated Voltage :
48VDC
Rated Current :
6.5A
Motor Speed(open) :
13000RPM
Motor Speed(closed) :
16000rpm
Driving Motor :
3 Phase Brushless DC Motor
Bearing :
NMB Ball Bearing
Air Pressure :
12.5Kpa
Noise :
85dBA
Net Weight :
1500g
IP Grade :
IP 54
Service Life :
10000 Hours
Description

OWB1412 Series Brushless DC air blower

48V DC air vacuum blower for vacuum cleaner,Air purifier,Hand dryer,
Air bubble machine , Ventilating device

Description:

1. Appearance: The fan adopts aluminum alloy + plastic cover and wind blade aluminum combination.

2. Features: compact structure, stable operation, low noise , long life.

3. Uses: The most suitable choice for atmospheric particulate matter sampler, dust sampling instrument, medical cough machine, ventilator, fresh air system!

2: Products Parameters

Model OWB1412-140 OWB1412-130
Rated Voltage 48VDC 48VDC
Rated current(open) 8A 6.5A
Air flow(open) 84M3/H 80M3/H
Motor Speed(open) 14000 RPM 13000RPM
Rated current(closed) 5.6A 3.7A
Air pressure(closed) 14.5kPa 12.5kPa
Motor Speed(closed) 16900 RPM 16000RPM
Motor pole 4 4
Phase Resistance 0.9 Ohm 1.0 Ohm
Noise 88 dBA 85 dBA
Ball Bearing NMB High-speed ball bearing
Driving motor 3 phase brushless DC motor
Hall sensor angle 120°
RPM-Pulse 1 Hz=30rpm/min
Winding type Delta
Winding withstand Voltage 500VDC (1 minute )
Insulation Class Class F
Blower weight 1500g
IP grade IP54
Operation temperature -20℃~ 50℃
Service life (under 40℃) 10000 hours

3: Products performance

OWB1412 brushless DC vacuum blower commutating period

Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion

OWB1412 brushless DC blower Performance curves

Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion

Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion

Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion



4: Overall dimensions

Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion


5: Wiring diagram
Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion

Pin 4 Red +5V
Pin 5 Purple Hall A
Pin 6 Green Hall B
Pin 7 Grey Hall C
Pin 8 Black GND
Pin 1 Yellow Motor phase A
Pin 2 Blue Motor phase B
Pin 3 White Motor phase C


6: Attentions
1: Do not working under the max air pressure, the air flow is too small at max air pressure, and it's not safe for using.
2: Add a filter attach to the intake makes the blower bearing longer service life.
3: The correct rotation direction is CCW
4: Do not use the blower in High temperature ,high humidity, high magnetic fields
5: Please use suitable power supply for the blower.

7: Brushless DC Air Blower Applications:
1: Buffer air cushion
2: Intelligent closestool
3: Electric-Drive phlegm-Sucker
4: Central ventilation system
5:Air purifier
6:Hand dryer
7: Air bubble machine
8: Ventilating device
9: Vacuum cleaner
10: breathing machine
11: air pump
12: Cooling equipment

Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion

Packing:

Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion

Shipment:

Low Noise 48V Vacuum DC Brushless Blower 12.5Kpa 80M3/H For Buffer Air Cushion

FAQ:

Can we connect this centrifugal air blower directly onto power source?

This blower fan is with BLDC motor inside and it needs a controller board to run.

What kind of power source shall we use to drive this blower fan?
Generally, our customers use 24vdc switching power supply or Li-on battery.

Do you also sell controller board for this blower fan?
Yes, we can supply adapted controller board for this blower fan.

How to change impeller speed if we use your controller board?
You can use 0~5v or PWM to change speed. Our standard controller board is also with a
potentiometer to change speed conveniently.

What is the MTTF of this centrifugal air blower?
MTTF of this centrifugal air blower is 20,000+ hours under 25 C degree.

Can we use this centrifugal air blower to suct water?
This blower fan can not be used to suck water. If you need to suck water, you can ask us to
choose proper item for this special working condition.

Can we use this centrifugal air blower to suck dust directly?
This blower fan can not be used to suck dust directly.If you need to suck dust, you can ask
us to choose proper item for this special working condition.

What can do if the working condition is dirty?
A filter is strongly recommended to assemble onto the the inlet of the blower fan

How to decrease the noise of the blower?
Many of our customers use foam, silicone to fill between blower fan and machine to insulate
the blower noise.
