Remote Control 12v Dc Sensorless BLDC Fan Driver Speed Controller
Remote Control 12v Dc Sensorless BLDC Fan Driver Speed Controller
Remote Control 12v Dc Sensorless BLDC Fan Driver Speed Controller
Remote Control 12v Dc Sensorless BLDC Fan Driver Speed Controller
Specifications
Model Number :
OWFD-FL004
Place of Origin :
China
MOQ :
5
Price :
Negotiable
Voltage input :
DC12V
Power :
36W
Working current :
3A
Motor :
sensorless motor
Description

DC12V Input BLDC Ceiling Fan Controller Driver Remote Control High Performance

DC12V input,BLDC ceiling fan controller driver,remote control,FOC brushless motor ceiling fan driver

Remote Control 12v Dc Sensorless BLDC Fan Driver Speed Controller

Model number:OWFD-FL004

Voltage input DC 12V
Power 36W
Efficiency 87%
PF 0.94

Fan Motor driver specification

Drive mode sinusoid / sine wave drive,FOC
Motor sensorless motor
Speed 0-400 RPM
Speed control RF/PWM/VSP/SPI
Speed feedback Yes
Forward/reverse No

Protections

Over voltage protection 16V
Low voltage protection 9V
Locked-rotor protection Yes
Phase loss protection Yes
Over current / Over load 6A
Limit current protection 4A
Reverse polarity protection Yes

Model selection

Model Power input Voltage Power AC range Working range Speed feedback Forward/ Led lights Size(mm)
reverse
OWFD-LF003 DC DC12V 36W / 7-26V Yes Optional Optional 75*35
OWFD-LF004 DC DC12V 36W / 5-26V Yes Optional Optional Dia:75
OWFD-LF005 DC DC12V 36W / 7-28V Yes Optional Optional 75*55
OWFD-LF007 DC DC12V 36W / 5-28V Yes Optional Optional 84*41
OWFD-LF201 DC DC24V 36W / 18-30V Yes Optional Optional 75*55
