Electric Brushless 24mm 24v 6v Geared Dc Motor
Electric Brushless 24mm 24v 6v Geared Dc Motor
Electric Brushless 24mm 24v 6v Geared Dc Motor
Electric Brushless 24mm 24v 6v Geared Dc Motor
Electric Brushless 24mm 24v 6v Geared Dc Motor
Electric Brushless 24mm 24v 6v Geared Dc Motor
Electric Brushless 24mm 24v 6v Geared Dc Motor
Electric Brushless 24mm 24v 6v Geared Dc Motor
Specifications
Brand Name :
OWO
Model Number :
OW24ZYJ
Certification :
CE, Rohs
Place of Origin :
china
MOQ :
50pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union,PAYPAL
Supply Ability :
10000PCS/Month
Delivery Time :
as confirmed
Packaging Details :
suite for export
temperature rise :
40K
environment temperature :
-20℃~+80℃
Insulation Resistance :
100MΩ min 500VDC
Rated voltage :
6~24v
Rated Power :
0.06~9.6w
Rated speed :
3000~10000rpm
Weight :
50g
Description
24mm DC gear motor , high efficiency 6~24vdc voltage in put, max power 9.6W

OW24ZYJ DC gear motor

Electric Brushless 24mm 24v 6v Geared Dc Motor

​Features:

OW24ZYJ DC gear motor has the characteristics of simple structure, low noise, constant speed and long service life

Gernoral Specification:

Temperature rising: 40K

Environment temperature: -20℃~+80℃

Insulation resistance: 100MΩ min 500VDC

Insulation voltage: 500VAC for 1min

Insulation level: E

GENERAL SPECIFICATIONS:
Model specification OW24ZYJ
Use voltage DC/V 1.5V-24
Reduction ratio 1/16 1/25 1/85 1/200 1/466
No-load speed rpm 500 320 92 40 17
No-load current mA 45 45 45 45 45
Output torque g.cm 70 100 300 600 1500
Load speed rpm 450 290 80 32 14
Load current mA 100 100 100 100 100
Power W 2-3.5
Running direction Bidirectional reversible

ELECTRICAL SPECIFICATIONS:

Model Rated voltage motor speed Gear ratio power No-load speed No-load current Rated speed Rated current Rated load stall torque stall current
V DC rpm 1:xxx W rpm mA rpm mA Kg.cm Kg.cm mA
OW24ZYJ-25A 5 5000 200 2 25 30 20 100 1 3 500
OW24ZYJ-60A 9 5000 80 2 60 30 50 100 0.5 2 600
OW24ZYJ-17A 12 8000 466 2 17 35 14 120 2 5 600
Normal gear ratio:1/16 1/24 1/80 1/200 1/466 1/615
Above are normal products, we can make as the customer's request.

Drawing :

Electric Brushless 24mm 24v 6v Geared Dc Motor
