New Semi-automatic Capsule Filling equipment with PLC control
New Semi-automatic Capsule Filling equipment with PLC control
New Semi-automatic Capsule Filling equipment with PLC control
New Semi-automatic Capsule Filling equipment with PLC control
New Semi-automatic Capsule Filling equipment with PLC control
New Semi-automatic Capsule Filling equipment with PLC control
New Semi-automatic Capsule Filling equipment with PLC control
New Semi-automatic Capsule Filling equipment with PLC control
Specifications
Brand Name :
HUALE MACHINERY
Model Number :
DTJ-V
Certification :
CE ISO9001
Place of Origin :
CHINA
MOQ :
1 Set
Price :
$6000 /Set
Supply Ability :
15 Setsper month
Delivery Time :
30 working days after received your payment
Packaging Details :
packed in plastic bag and fixed in export wooden box
Machine Name :
Semi-automatic capsule filling machine
Features :
can filling powder, pellet, micro-pills,granuals
Capsule Size :
000#,00#,0#,1#,2#,3#,4#,5# Are Available
Vacuum pump :
attached
After-sales Service Provided :
Engineers Available To Service Machinery Overseas
Driven Type :
Electric
control system :
PLC programming control with touch screen
certification :
CE
Description

New Semi-automatic Capsule Filling Equipment with PLC control

New Semi-automatic Capsule Filling equipment with PLC control

Application

It is a special capsule filling machine which is suitable for capsule filling with powder or granules.

It is suitable for medium & small pharmaceutical factory,,hospital preparation lab.etc.

General Description

The DTJ-V Capsule-Filling Machine is a new type of medicine filling machine with novel structure and attractive appearance. Under both electrical and pneumatic control and equipped with and automatic electronic counter and computer-controlled speed-adjusting device, the machine can accomplish the positioning, separation and locking etc. of capsules. In place of manual capsule-filling, it can reduce labor intensity and raise productivity. Its filling amounts are accurate and up to sanitary standards for pharmaceutics.

Main parameters

Capsule size No. 000#-5#
Capacity(capsules/h) 10000-22500((Depending on the operation of skilled workers)
Power supply 380V 3Pharse 4.0kw
Vacuum pump 40m3/h
Capacity of air compressor(is not included, prepared by customers) 0.03m3/min 0.7Mpa
Overall dimensions:(mm) 1140×700×1630
Packing dimension:(mm) 1650×800×1750
Net weight:(Kg) 430
Gross weight:(Kg) 500
