► Duplex carton is a thick paper-based material. While there is no rigid differentiation between paper and paperboard.
► Duplex carton is generally thicker (usually over 0.30 mm, 0.012 in, or 12 points) than paper and has certain superior attributes such as foldability and rigidity. According to ISO standards, paperboard is a paper with a grammage above 250 g/m2, but there are exceptions. Paperboard can be single- or multi-ply.
► Duplex carton can be easily cut and formed, is lightweight, and because it is strong, is used in packaging. Another end-use is high quality graphic printing, such as book and magazine covers or postcards. Paperboard is also used in fine arts for creating sculptures.
Paper raw material | recycled pulp, waste paper pulp |
Size available | 600, 700, 900, 1000, 1100, 1160mm, etc in roll
640 * 960, 700 * 1000, 1000 * 1000mm, etc. in sheet
other size can be customized, just contact us freely |
Basic weight available | 200, 230, 250, 300, 350, 400, 450gsm. if need thicker, just contact us |
Sample | A4 size free of charge, large sheet or roll sample also available. |
Color | one side white, the other side is grey |
Quality | AAA, AA |
Properties | Unit | GSM & QUALTIY | |||||||
Basic weight | g/m2 | 200 | 230 | 250 | 270 | 300 | 350 | 400 | 450 |
Basic weight tolerance | % | ±7 | |||||||
Caliper | μm | 230±15 | 280±15 | 305±15 | 330±15 | 365±15 | 430±15 | 495±15 | 550±15 |
Moiture | % | 6.5±1.5 | 7.0±1.5 | 7.5±1.5 | 7.5±1.5 | 7.8±1.5 | 8.0±1.5 | 8.0±1.5 | 8.0±1.5 |
Stiffness(Taber) CD/MD | ≥ g.cm | 13 / 26 | 13 / 26 | 15 / 30 | 22 / 50 | 35 / 70 | 55 / 110 | 70 / 140 | 85 / 170 |
Top COBB Value | g/m2 | ≤ 50 | |||||||
Back COBB Value | g/m2 | ≤ 300 | |||||||
SD Difference of Gram | % | ≤ 3.5 | |||||||
SD Difference of Caliper | % | ≤ 3.5 | |||||||
Roughness | μm | ≤ 2.0 | |||||||
Brightness ( Top ) | % | ≥ 76 | |||||||
Folding Endurance CD | times | ≥ 12 | |||||||
Gloss (75°) | % | ≥ 35 | |||||||
Printing gloss | % | ≥ 80 | |||||||
Ply Bonding | J/m2 | ≥ 130 |
1. Sheet Packing: Plastic film wrapped on strong wooden pallets with four 4 angle protector)
2. Roll Packing: Kraft paper/Film wrapped outside on strong wood pallets or without pallet.
courier bags | indirect-contact food boxes | cosmetics package |
medicine carton | clothes lining board | shoe box |
