Specifications
Brand Name :
Lvjoe
Model Number :
lvjoe
Certification :
CE ISO
Place of Origin :
Mainland, China
MOQ :
1 line
Price :
100,000-200,000 USD
Payment Terms :
L/C, T/T
Supply Ability :
5 lines per year
Delivery Time :
2 months
Packaging Details :
standard package
Power(W): :
800-1200kw
Production Capacity :
3million-10million M2/YEAR
Voltage :
380V/220V/415V
Dimension(L*W*H) :
12600*1950*1600mm
Thickness :
7-15mm
Advantage :
Environment Friendly
Description

Automatic Calcium Silicate Insulation Wall Board Making Machines

Introduction:

Calcium Silicate Board is a new type decorative material,which is made from high-grade siliceous materials and lime refactory with the mixture of the natural fiber as reinforcing material.

We supply 5 million sqm one year

Main row material one day

cement50T

fiber 2-3T

assistance material10T

water 100T

water about 100T(can be reuse again)

Item

Unit

Standard Fiber Reinforced Calcium Silicate Board

Density

g/cm3

<1.2

Anti-bend strength

MPa

>9

Heat conduction modulus

w/m.k

<0.29

Anti-impact strength

kJ/mm2

>2.0

Pull force of screw

N/mm

>75

Dry shrinkage rate

%

<0.2

Non-burn performance

In accordance with standard GB8624 First ClassNon-burn Material

Electrical

A mechanical and electrical capacity of 400 KW or so explosive filling, shall be equipped

with transformer SC400/10 type a, Some high and low voltage switchgear.

water required

Because the water hardness smaller rivers water source, the production water water had better

use after precipitation. The JiangHeShui. This condition can be used without the drinking water

(or processed neutral water), are also available. The hardness of smaller groundwater. The water

hardness is too big, easy to make products brittle increases, and influence. Some parts of the

filter host water performance

Advantage

1 Configuration dust collector, eliminate dust flying, collecting dust to used for production

2 The "closed-circuit circulation", including alkali water not out flow

3All waste recycling, to used for production
