RX24 25W 100R Wirewound Resistor For Motor
RX24 25W 100R Wirewound Resistor For Motor
RX24 25W 100R Wirewound Resistor For Motor
RX24 25W 100R Wirewound Resistor For Motor
RX24 25W 100R Wirewound Resistor For Motor
RX24 25W 100R Wirewound Resistor For Motor
RX24 25W 100R Wirewound Resistor For Motor
RX24 25W 100R Wirewound Resistor For Motor
Specifications
Brand Name :
BOCHEN
Model Number :
RX24
Certification :
RoHS, REACH
Place of Origin :
Chengdu
MOQ :
50 Pieces
Price :
$0.48 - $15.00/Piece
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
3,000,000 Pieces Per Month
Delivery Time :
1-7 Workdays
Packaging Details :
Standard packing or according to customers requirements
Product Name :
RX24 25W 100R Wirewound Resistor
Product Type :
Wirewound Resistor
Termination Style :
Solder Lug
Mounting Style :
Chassis Mount
Resistance Range :
0.1Ω~50KΩ
Resistance Tolerance :
±1%, ±5%
Rated Power :
25W
Withstand Voltage :
AC1KV~AC2KV，50Hz/5s
Operating Voltage :
＜1KV
Description

RX24 25W 100R Wirewound Resistor For Motor

RX24 25W 100R Wirewound Resistor For Motor

BOCHEN is one of the leading china suppliers of standard and custom designed aluminium housed resistors for general-purpose use, power supplies, power generation and the traction and drives industries. The RX Series product offering, a range of extremely stable, high-quality wire wound resistors are made from quality materials for optimum reliability and stability, capable of dissipating high power in a limited space with relatively low surface temperature. The aluminium housing in these resistors help rapidly dissipate power to a specified heat sink.

RX24 25W 100R Wirewound Resistor For Motor

Features:

• Established product with proven reliability leading the waywith over 20 years of design and manufacturing experience.
• 5 Watts to 500 Watts: Largest range on the market.
• Versatile product bench mark in wide range of industries.
• Custom designs, windings, terminations, mountingsavailable on request.
• Low resistance, low inductance and higher voltage versionsavailable specialising the standard.

RX24 25W 100R Wirewound Resistor For Motor

Specification:

Rated power at 25℃(W)

Resistance

Range (Ω)

Resistance

Tolerance (%)

 TCR
(×10-6/℃)		 Voltage (V)
With heatsink Without heatsink
5 3 0.01~1K ±1, ±5 ±100, ±50 1000
10 8 0.01~1.5K
20 12.5 0.01~10K
30 15 0.01~27K
50 20 0.01~33K
75 45 0.01~39K
100 50 0.01~51K 2000
150 55 0.01~56K
200 50 0.01~62K
250 60 0.01~68K
300 75 0.01~75K
500 200 0.01~82K

Dimension:

RX24 25W 100R Wirewound Resistor For Motor

Rated Power Dimension(mm)
L1±1 L2±1 L3±1 L4±1 A±1 B±1 C±1 D±0.3 E±0.3 H±1 h±1 T±0.2
RX24-5W 60 15 115 0 17 13 9.5 0.6 2.2 8 4 1.6
RX24-10W 65 20 14.5 0 23 16 11 0.7 3.5 10.5 5.2 2
RX24-25W 49 27 19 0 28 20 16 2 3.5 15.5 7 2
RX24-50W 70 50 39.5 0 28 21.5 16 2 3.5 15.5 7 2
RX24G-75W 90 70 39.5 0 28 21.5 16 2 3.5 15.5 7 2
RX24G-75W 100 66 36 0 48 37 27 4 5 26 13 3.5
RX24G-100W 130 98 71 35.5 48 37 27 4 5 26 13 3.5
RXG24G-150W 170 136 110 55 48 37 27 4 5 26 13 3.5
RXG24G-200W 190 155 126 63 48 37 27 4 5 26 13 3.5
RXG24G-200W 127 92 66 33 72 58 46 6 6 43 22.5 5
RXG24G-250W 147 112 86 43 72 58 46 6 6 43 22.5 5
RXG24G-300W 160 128 105 52 72 58 46 6 6 43 22.5 5
RXG24G-500W 230 200 175 87 72 58 46 6 6 43 22.5 5
RXG24G-800W 280 250 222 110 72 58 46 6 6 43 22.5 5
RXG24G-1000W 330 300 250 125 72 58 46 6 6 43 22.5 5

Application:

• Braking Resistor.
• Balancing Resistor.
• Capacitor Charging&Discharging.
• Crowbar.
• Filter.
• Electrical Machinery general use.
• Available through Distribution.
