Cermet Trimmer 3296W-A Potentiometer Trimpot 8mm Vertical Shaft Knob
Cermet Trimmer 3296W-A Potentiometer Trimpot 8mm Vertical Shaft Knob
Cermet Trimmer 3296W-A Potentiometer Trimpot 8mm Vertical Shaft Knob
Cermet Trimmer 3296W-A Potentiometer Trimpot 8mm Vertical Shaft Knob
Cermet Trimmer 3296W-A Potentiometer Trimpot 8mm Vertical Shaft Knob
Cermet Trimmer 3296W-A Potentiometer Trimpot 8mm Vertical Shaft Knob
Cermet Trimmer 3296W-A Potentiometer Trimpot 8mm Vertical Shaft Knob
Cermet Trimmer 3296W-A Potentiometer Trimpot 8mm Vertical Shaft Knob
Cermet Trimmer 3296W-A Potentiometer Trimpot 8mm Vertical Shaft Knob
Cermet Trimmer 3296W-A Potentiometer Trimpot 8mm Vertical Shaft Knob
Specifications
Brand Name :
BOCHEN
Place of Origin :
Chengdu
Model Number :
3296W-A
Certification :
RoHS, Reach
MOQ :
100 Pieces
Price :
$0.048 - $0.90/Piece
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
3,000,000 Pieces Per Month
Delivery Time :
1-7 Workdays
Packaging Details :
50 pieces per tube, 20 tubes per box.
Product Name :
3296W-A 8mm Vertical Long Adjustment Shaft Knob Cermet Trimmer Potentiometer
Product Type :
Multiturn Trimmer Resistors
Element Type :
Cermet
Mounting Style :
PCB Mount
Termination Style :
PC Pin
Nominal Resistance Range :
10Ω~5MΩ
Resistance Tolerance :
±10%
Contact Resistance Variation (CRV) :
≤3%R or 3Ω
Rated Power(300 volts max.) :
70℃, 0.5W; 125℃, 0W
Effective Travel :
25±2 Turns
Description

3296W-A 8mm Vertical Long Adjustment Shaft Knob Cermet Trimmer Potentiometer

Quick Detail:

​​

● 0.5W at 70℃.

● 8mm vertical adjustment shaft.

● Multi-finger wiper for better CRV.

● Wide ohmic range (10 Ω to 5 MΩ).

● 30±2 turns total mechanical travel.

● Multiturn / Cermet / Industrial / Sealed.

Description:

The 3296W-A trimmer potentiometer is a precision electronic component utilized for fine-tuning resistance in circuits. Renowned for its high resolution and durability, this trimmer potentiometer ensures stable resistance values even under fluctuating conditions. Its multi-turn design allows for precise adjustments, making it ideal for applications requiring accuracy, such as audio equipment, instrumentation, and communication devices. The 3296W-A trimmer potentiometer is favored by engineers for its reliability and compact size, facilitating its integration into various electronic systems with ease.

Specification:

Electrical Characteristics Nominal Resistance Range 10Ω~5MΩ
Resistance Tolerance ±10%
Terminal Resistance ≤±1% R or 3Ω
Contact Resistance Variation (CRV) ≤3%R or 3Ω
Insulation Resistance 500 Vdc. R1≥1GΩ
Withstand Voltage 101.3KPa, 500 Vac; 8.5KPa, 250 Vac
Dielectric Strength Sea Level 500 Vac(1 Min.)
Effective Travel 25(±2)Turns
Environment Characteristics Weld Heat Resistance Wave soldering:
Temp: 260ºC±5ºC, T: 3±1 Secs.
Soldering iron welding:
Temp: 320ºC±5ºC, T: ≤2 Secs.
Rated Power(300 volts max.) 70ºC, 0.5W; 125ºC, 0W
Temperature Range -55°C ~ + 125°C
Temperature Coefficient ±250,±100 ppm /°C
Temperature Variation ΔR≤±2%R, Δ(Uab/Uac)≤±1%
Collision 10-500Hz, 0.75mm, 6h ΔR≤±1%R, Δ(Uab/Uac)≤±2%
Vibration 100G, ΔR≤±1%R, Δ(Uab/Uac)≤±2%
Electrical Endurance At 70°C 1000 hours @ 70ºC Rated Power; ΔR≤±3%R
Rotational Life 200 Cycles, ΔR≤±3%R
Physical Characteristics Total Mechanical Travel 30±2 Turns
Starting Torque ≤25 mN.m
Clutch Torque ≤35 mN.m

Dimension:

Cermet Trimmer 3296W-A Potentiometer Trimpot 8mm Vertical Shaft Knob

Packaging:

Packaging specification: 50 pieces per tube, 20 tubes per box.


Application:

• Industrial control.
• Communication equipment.
• Precision instruments.
• Automotive electronics.
• LCD panels.
• Switching power supplies.



Advantage:

• Factory direct supply, no middlemen.
• Completed certificates such as RoHS, REACH,etc and best quality assurance.
• Sufficient production capacity, short delivery time.
• Professional after-sales service team.
• OEM&ODM available.
