RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor
RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor
RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor
RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor
RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor
RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor
RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor
RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor
RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor
RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor
Specifications
Brand Name :
BOCHEN
Model Number :
RX24
Certification :
RoHS, REACH
Place of Origin :
Chengdu
MOQ :
50 Pieces
Price :
$3.25 - $3.78/piece
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
3,000,000 Pieces Per Month
Delivery Time :
1-7 Workdays
Packaging Details :
Standard Packing
Product Name :
RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor
Product Type :
Aluminum Housed Wirewound Resistor
Termination Style :
Solder Lug, screw
Mounting Style :
Chassis Mount
Nominal Resistance Range :
0.1 ohm ~ 68k ohms
Resistance Tolerance :
±5%
Power Rating :
5W ~ 500W
Description

RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor

Feature

• 5 Watts to 500 Watts: Largest range on the market.
• Versatile product bench mark in wide range of industries.
• Custom designs, windings, terminations, mountingsavailable on request.
• Low resistance,low inductance and higher voltage versionsavailable specialising the standard.

• Established product with proven reliability leading the waywith over 25 years of design and manufacturing experience.

Description

The RX24 Wirewound Resistor is a high-power, precision component designed for applications demanding excellent heat dissipation and robust performance. Encased in an aluminum housing, this resistor provides superior thermal management, allowing it to operate efficiently under high power loads. The wirewound construction ensures precise resistance values and exceptional stability, making the RX24 ideal for use in power supplies, motor drives, industrial machinery, and other high-power electronic applications.

The RX24 offers a wide range of resistance values with tight tolerances, catering to various circuit requirements. Its aluminum housing not only enhances heat dissipation but also protects the resistor from environmental factors, ensuring long-term reliability and durability. This resistor is designed to handle high surge currents and can operate effectively in demanding environments, making it a versatile choice for engineers and designers.

Additionally, the RX24 is equipped with mounting holes for easy installation and integration into different systems. Its robust design and high power-handling capability make it suitable for applications where reliability and performance are critical. Whether used in braking systems, power conversion units, or load testing equipment, the RX24 Aluminum Housed Wirewound Resistor delivers consistent and dependable performance.

Specification

Rated Power At 25℃(W) Range (Ω) Tolerance (%) T.C.R.
(×10-6/℃)		 Voltage (V)
With Heatsink Without Heatsink
5 3 0.01~1K ±1, ±5 ±100, ±50 1000
10 8 0.01~1.5K
20 12.5 0.01~10K
30 15 0.01~27K
50 20 0.01~33K
75 45 0.01~39K
100 50 0.01~51K 2000
150 55 0.01~56K
200 50 0.01~62K
250 60 0.01~68K
300 75 0.01~75K
500 200 0.01~82K

Dimension

Rated power at 25℃(W)with heatsink@25℃ Dimension(mm)
Weight(g)
A max B L H C I I1 M N Φ 1 Φ2 Surface area (cm2) Thickness (mm)
5 15.5 16 36.5 8 8.5 11.4 12 4.4 1.5 1.5 2.2 415

1

 3
10 19.5 21 40.5 10 11.2 14 16 5 2 2 2.5 415 6
20 27 27 48.0 13 14.3 18.3 20 7 2 2 3.5 535 11
30 34.0 29 55.0 15.5 16.3 25 22 7.3 2 2 3.5 535 18
50 50 29 71 15.5 16.3 40 20.5 7.3 2 2 3.5 995 30
75 65.5 48 86.5 26 27 23.5 37 11.5 3.5 3 4.4 995



3



 90
100 98 48 119 26 27 35 37 11.5 3.5 3 4.4 995 160
150 130 48 151 26 27 52 37 11.5 3.5 3 4.4 995 240
75 65.5 48 93.5 26 27 23.5 37 11.5 3.5 M3 4.4 995 90
100 98 48 126 26 27 35 37 11.5 3.5 M3 4.4 995 160
150 130 48 158 26 27 52 37 11.5 3.5 M3 4.4 995 240
200 92 73 132 45 46.5 35 58 21 5 M6 5.5 3750 420
250 112 73 152 45 46.5 45 58 21 5 M6 5.5 4765 480
300 130 73 170 45 46.5 51 58 21 5 M6 5.5 5780 580
500 204 73 244 45 46.5 87 58 21 5 M6 5.5 8500 970

RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor

Application

• Braking resistor Balancing resistor.
• Capacitor charging&discharging.
• Crowbar.
• Filter.
• Electrical machinery general use.

RX24 500W 10K 5% Gold Aluminum Housed Wirewound Power Resistor Dynamic Braking Resistor

Advantage

• Factory direct supply, no middlemen.
• Completed certificates such as RoHS, REACH, etc and best quality assurance.
• Sufficient production capacity, short delivery time.
• Professional after-sales service team.
• OEM & ODM available.
