RIG High Power Rf 500W 100 Ohm Resistor
RIG High Power Rf 500W 100 Ohm Resistor
RIG High Power Rf 500W 100 Ohm Resistor
RIG High Power Rf 500W 100 Ohm Resistor
RIG High Power Rf 500W 100 Ohm Resistor
RIG High Power Rf 500W 100 Ohm Resistor
Specifications
Brand Name :
BOCHEN
Model Number :
RIG22
Certification :
RoHS, REACH
Place of Origin :
Chengdu
MOQ :
100 Pieces
Price :
$0.98 - $1.80/Piece
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
1,000,000 Pieces Per Month
Delivery Time :
1-7 Workdays
Packaging Details :
Standard packing or according to customers requirements
Product Category :
RF Resistors
Power Rating :
1~1000W (70°C)
Resistance :
1Ω~500Ω
Tolerance :
5%
Termination Style :
SMD/SMT
Product Type :
High Frequency/RF Resistors
Temperature Range :
-55℃~+165℃
Description

RIG High Power Rf 500W 100 ohm Resistor

Overview


The RIG22 series is a high-performance thick film power resistor designed for RF and microwave applications. Engineered with excellent high-frequency characteristics and power endurance, it is ideal for environments that demand stability, precision, and reliability. With power ratings up to 1000W, wide resistance range, and excellent environmental resistance, RIG22 is suitable for critical systems where consistent performance is essential.

RIG High Power Rf 500W 100 Ohm Resistor

Features

• Rated Power: Up to 1000W
• Resistance Range: 1Ω ~ 500Ω
• Flameproof construction for high safety
• Excellent long-term stability and reliability
• Operating Temperature: -55°C to +165°C
• Ideal for high-load and high-temperature applications

RIG High Power Rf 500W 100 Ohm Resistor

Specifications

Electrical Characteristics Nominal resistance range 1 ~ 500Ω
Resistance tolerance ±5%
Frequency range 0 ~ 2GHz
Standing wave ratio 1.2 ~ 1.3
Insulation resistance ≥ 1GΩ
Withstand voltage 500V / 1 mm (Substrate thickness)
Environmental Characteristics Rated power 1~1000W (at 70°C)
Temperature range -55°C ~ +165°C
TCR (Temperature Coefficient) ±300 × 10⁻⁶ /°C
Temperature shock (-55°C/+125°C, 3 times) ΔR ≤ ±5%R
Moisture proof (GJB306A-96 Method 106) ΔR ≤ ±5%R
Vibration (10–500Hz, 0.75mm, 6h) ΔR ≤ ±3%R, no mechanical damage
Low temp. test (-55°C, 24h) ΔR ≤ ±5%R
Load life (96h) ΔR ≤ ±5%R
Collision ΔR ≤ ±3%R
Physical Characteristics Terminal strength No loose and fall off
Solderability (240°C, 3s) Tin layer covering area ≥ 95%

Applications

  • RF and microwave circuits

  • Radar and satellite communication systems

  • Power amplifiers and attenuators

  • Test and measurement equipment

  • Military and aerospace electronics

  • Industrial automation and instrumentation

RIG High Power Rf 500W 100 Ohm Resistor

Whether used in high-power circuits or precision instrumentation, the RIG22 delivers consistent and dependable performance across a broad spectrum of industries.

Advantage

• Factory direct supply, no middlemen.
• Completed certificates such as RoHS, REACH, etc and best quality assurance.
• Sufficient production capacity, short delivery time.
• Professional after-sales service team.
• OEM & ODM available.
