CO2 Fractional Laser 10600 nm Skin Resurfacing Stretch Marks Removal Pigmentation Acne Scars Cure
Fractional resurfacing is a new modality for laser treatment that creates numerous microscopic thermal injury zones with
controlled width, depth, and density that are surrounded by a reservoir of spared epidermal and dermal tissue, allowing for rapid repair of laser induced thermal injury.
This unique modality, if implemented with proper laser delivery systems, enables high energy treatments while minimizing risks.
The fractional co2 laser produces a beam of infrared light with the principal wavelength bands centering around 9.4 and 10.6 micrometers. With fractional laser resurfacing the laser beam is broken up or fractionated into many small micro beams which are separated so that when they strike the skin surface small areas of the skin between the beams are not hit by the laser and left intact. These small areas of untreated skin promote a much more rapid recovery and healing with less risk of complications. The small areas treated by the fractional micro beams, called micro treatment zones, cause sufficient laser injury to promote new collagen production and resultant facial skin rejuvenation.

Fractional co2 laser machine Applications:
- Skin renewing and resurfacing;
- Skin tightening;
- Acne and acne scar removal;
- Smooth burnt scars and surgery scars, dermabrasion etc-;
- Remove intractable chloasmas and pigmentation;
- Sun damage recovery

Laser type | RF-excited Co2 laser |
Wavelength | 10.6μm |
Laser average Power | CW: 0-30W SP: 0-14W | CW: 0-15W SP: 0-7W |
Laser peak power | CW: 30W SP: 60W | CW: 15W SP: 30W |
| Surgical hand pieces (F50mm, F100mm) |
Scan hand pieces (F50mm, F100mm) |
Gynecology handpieces ( F127mm) |
Spot size | 0.1mm |
Scan size | up to 20mm*20mm |
LCD touch screen | 12. inch |
Aiming beam | 635nm, <5mW |
Electrical requirement | 100-240VAC, 50-60Hz, 800VA (not including articulated arm) |
Dimension(W×D×H) | 460mm×430mm×1170mm |
Weight | 40kg |
