Specifications
Brand Name :
Dehai Boiler
Model Number :
Superheater
Certification :
ISO9001 , SGS , ABS , ASME
Place of Origin :
China (Mainland)
MOQ :
10 Tons
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
800 Tons / Month
Delivery Time :
45 Days
Packaging Details :
Seaworthy packing
Type :
Natural Circulation
Structure :
Water Tube
Fuel :
Gas-fired
Keywords :
Boiler Supeheater
Description

Boiler Spare Parts Superheater For Utility Power Station High Efficiency Heat Exchanger hot water boiler

Boiler Spare Parts Superheater Features

1. As outstanding features, Heat Efficiency Improving boiler parts reheater for Steam Boiler have beautiful appearance, accurate sizes, advanced bending and welding technique, first-lass testing equipment and guaranteed quality.

2. The function of Super heater in the thermal power plant is to remove the last traces of moisture from the saturated steam coming out of boiler and to increase its temperature above saturation temperature as per requirement at inlet of steam turbine.

Brief Introduction

1. Generally 30 ~ 60 mm.The most common type of flow superheater is serpentine tube.It has a more intensive tube group, decorate in 450 ~ 1000 ℃ flue of the flue gas temperature, flue gas of vertical and lateral erosion.The flue gas mainly transfers the heat to the pipe by convection, and some of the heat is absorbed by radiation.

2. The plate-type superheater consists of a plurality of tube screens, arranged in the upper part of the furnace or at the outlet, belonging to the radiation or semi-radiation type superheater.The former absorbs radiant heat from the furnace flame, while the latter also absorbs some convection heat.

Technical Parameter

Type
Advantages
Disadvantages
Pendant-type
1.Firm structural support
1. Flow blockage by condensed steam 2. Needs slow restart to purge the water that accumulates in the bottom.
Inverted-type
1.Proper drainage of the condensed steam
1. Lack the structural rigidity, especially in high speed gas flow
Horizontal -type
1. Proper drainage
2. Good structural rigidity
1. They do not view the flam directly so they are mainly from the convective type
Material
carbon steel, alloy steel , or durable heat steel
Tube OD
30-60mm, or as per requirement
Tube W.T.
0.8mm- 15mm
Structure
vertical or horizontal
Type
radiant, convection superheater

Coil & Header Connection


Utility Heating Coil For Furnace Gas Fired Fuel Water Tube Natural Circulation
