H Finned Tube Double H Fin tube for heating transfer system High Quality

H Finned Tube Specification

1. H-economizer two rectangular fin, similar to a square, its edge length for the fluorescent tubes of 2-fold,an expansion of the heating surface.

2. H-economizer flash resistance welding processes used, the welding seam after the high rate of fusion, weld tensile strength, and has good thermal conductivity. H-economizer can also manufacture dual tube "double H" type fin tubes, its rigid structure, and can be applied to a longer tube row occasions.

3. Performance characteristics: Excellent anti-wear performance, Less fouling, Compact space, Welded joints less, Stability.

H fin tube, known as Square fin tube & H Finned economizer, finned tube, is used in boilers parts, marine power.

4. It is a kind of boiler parts, to have two steel circular symmetry to be welded on fluorescent tubes to form fins positive shap much like letter "H", so called H-fin tube. H-economizer widely used in utility boilers, industrial boilers, marine power, such as the tail of heat exchanger components.

Principle

1. H fin tube is a kind of boiler parts, to have two steel circular symmetry to be welded on fluorescent tubes to form fins positive shap much like letter "H", so called H-fin tube. H-economizer widely used in utility boilers, industrial boilers, marine power, such as the tail of heat exchanger components.

2. H-economizer two rectangular fin, similar to a square, its edge length for the fluorescent tubes of 2-fold, an expansion of the heating surface.

3. H-economizer flash resistance welding processes used, the welding seam after the high rate of fusion, weld tensile strength, and has good thermal conductivity. H-economizer can also manufacture dual tube "double H" type fin tubes, its rigid structure, and can be applied to a longer tube row occasion.

Working Condition

• Max. Working Temperature: 300 °C
• Atmospheric Corrorsion Resisitance: OK
• Mechanical Resistance: Good
• Fin Material: Copper, Aluminum, carbon steel, stainless steel
• Base Tube materials: Any material available, such as Carbon steel Tube, A179, A192, A210, stainless tube A269/A213 T5 T11 T22 304 316

Scope of H Finned Tube

Detailed Picture
