Industrial Fluidized Bed CFB Utility Boiler Power Plant , High Pressure Steam Boiler
Industrial Fluidized Bed CFB Utility Boiler Power Plant , High Pressure Steam Boiler
Industrial Fluidized Bed CFB Utility Boiler Power Plant , High Pressure Steam Boiler
Industrial Fluidized Bed CFB Utility Boiler Power Plant , High Pressure Steam Boiler
Industrial Fluidized Bed CFB Utility Boiler Power Plant , High Pressure Steam Boiler
Industrial Fluidized Bed CFB Utility Boiler Power Plant , High Pressure Steam Boiler
Industrial Fluidized Bed CFB Utility Boiler Power Plant , High Pressure Steam Boiler
Industrial Fluidized Bed CFB Utility Boiler Power Plant , High Pressure Steam Boiler
Specifications
Brand Name :
HD Boiler
Model Number :
CFB Boiler
Certification :
ISO9001,ASME,Grade A,SGS,EN,TUV
Place of Origin :
Zhangjiagang,Jiangsu,China
MOQ :
1Set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20 Sets /Year
Delivery Time :
Negotiation
Packaging Details :
Seaworthy Packing
Condition :
New
Structure :
Fluidized bed
Fuel :
Coal / Biomass
Water Circulation :
Natural circulation
Pressure :
High Pressure
Range of Applications :
Industrial/Power station
Specification :
Customized
Manufacturing Level :
A
Place Style :
Vertical
Burning StylBurning Style :
Fluidized Bed Furnace
Description

Saving Energy High Pressure CFB Boiler and Utility Boiler With ASME Standard

Product Description

HD boiler design and manufacture of a circulating fluidized bed boiler using clean combustion technology,the new boiler with high combustion efficiency and low pollution of typical characteristics of cleaning from the experience of other circulating fluidized bed boiler designed on the basis of optimizing.The coal adaptability ,can be applied to bituminous coal,lignite coal,lean coal,mixed coal and other different kinds of fuel,the combustion efficiency up to 99%.

Structure Features

  • Natural circulation water-tube boiler single boiler barrel, an n-shaped structure.
  • The hearth is membrane water wall hanging closed structure.
  • Adopting the water cooling air chamber and a water cooling cloth wind plate, under the bed of water.
  • Separated by high temperature insulation volute cyclone cylider, outer furnace arrangement.
  • Superheater, economizer, air preheater is arranged in the tail shaft.​​

Parameter

Model Capacity (t/h) Pressure(MPa) Steam temperature (ºC)

Feed water temperature

(ºC)

 Desulfurization efficiency
HD-35/3.82-M 35 3.82 450 150 min 82
HD-35/5.3-M 35 5.3 450 150 min 82
HD-75/3.82-M 75 3.82 450 150 min 82
HD-75/5.3-M 75 5.3 485 150 min 82
HD-75/9.8-M1 75 9.8 540 215 min 82
HD-130/3.82-M 130 3.82 450 172 min 82
HD-130/5.3-M 130 5.3 485 172 min 82
HD-130/9.8-M 130 9.8 540 215 min 82

Fuel:soft/lean/bituminou coal, anthracite,lignite,biomass and etc.

Industrial Fluidized Bed CFB Utility Boiler Power Plant , High Pressure Steam Boiler

Certifications

Industrial Fluidized Bed CFB Utility Boiler Power Plant , High Pressure Steam Boiler

Company Information

HD Boiler established in 1985, Zhangjiagang Hua Dong Boiler Co., Ltd. (trading as HD Boiler), is a professional industrial manufacturer, producing utility boiler,industrial boiler,HRSG boiler and all kinds of boiler parts, such as waterwall panels, economizers, air preheaters, superheaters, headers, spiral fin tubes, H-fin tubes, heat pipes etc. HD Boiler is located in Dong Lai Industrial Park, east suburb of Zhang Jia Gang City. The plant’s location is around 150km Expressway to Shanghai Port or 60km State Road to Suzhou or Wuxi, with transportation extending in all directions conveniently and quickly.

Industrial Fluidized Bed CFB Utility Boiler Power Plant , High Pressure Steam Boiler
