A179 / A192 T5 T11 T22 ASTM Carbon Steel Boiler Tubes
A179 / A192 T5 T11 T22 ASTM Carbon Steel Boiler Tubes
A179 / A192 T5 T11 T22 ASTM Carbon Steel Boiler Tubes
A179 / A192 T5 T11 T22 ASTM Carbon Steel Boiler Tubes
A179 / A192 T5 T11 T22 ASTM Carbon Steel Boiler Tubes
A179 / A192 T5 T11 T22 ASTM Carbon Steel Boiler Tubes
Specifications
Brand Name :
HDT
Model Number :
Boiler Steel Tube
Certification :
ISO, CE,
Place of Origin :
Suzhou,Zhangjiagang
MOQ :
20pcs
Price :
800 - 9000 USD / ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
About 10000 ton / month
Delivery Time :
30days
Packaging Details :
seaworthy packing for exporting
Product Name :
Carbon Steel Boiler Tube Heat Exchanger Seamless Tube
Type :
Seamless
Standard :
ASME/ASTM
Technical :
Cold Drawn
Description

A179/A192 T5 T11 T22 Seamless Steel Boiler Pipe/Tube ASTM


SA179/SA192 CHEMICAL AND MECHANICAL COMPONENT:

ASTM A179/(ASME SA179)
Seamless Cold Drawn Low Carbon Steel Heat Exchanger And Conderser Tubes
Application:
For tubular heat exchangers,condensers,and similar heat transfer apparatus.
Size(mm): O.D.:6.0~114.0 W.T.:1~15 L:max 12000
Grade and Chemical Composition (%)
Chemical Composition C Mn P≤ S≤ Si≤
0.06-0.18 0.27-0.63 0.035 0.035 0.25
Tolerance(SA-450/SA-450M):
OD In (mm) + - WT In(mm) + -
<1(25.4) 0.10 0.10 ≤1.1/2(38.1) 20% 0
1~1.1/2(25.4~38.1) 0.15 0.15 >1.1/2(38.1) 22% 0
>1.1/2~<2(38.1~50.8) 0.20 0.20
2~<2.1/2(50.8~63.5) 0.25 0.25
2.1/2~<3(63.5~76.2) 0.30 0.30
3~4(76.2~101.6) 0.38 0.38
>4~7.1/2(101.6~190.5) 0.38 0.64
>7.1/2~9(190.5~228.6) 0.38 1.14

ASTM A192/A192M-02
Seamless Carbon Steel Bolier Tubes for High-Pressure
Application:
For seamless carbon steel bolier and superheater tubes for high-pressure service
Size(mm): O.D.:6.0~114.0 W.T.:1~15 L:max 12000
Grade and Chemical Composition (%)
Chemical Composition C Mn P≤ S≤ Si≤
0.06-0.18 0.27-0.63 0.035 0.035 0.25
Tolerance(SA-450/SA-450M):
OD In (mm) + - WT In(mm) + -
<1(25.4) 0.10 0.10 ≤1.1/2(38.1) 20% 0
1~1.1/2(25.4~38.1) 0.15 0.15 >1.1/2(38.1) 22% 0
>1.1/2~<2(38.1~50.8) 0.20 0.20
2~<2.1/2(50.8~63.5) 0.25 0.25
2.1/2~<3(63.5~76.2) 0.30 0.30
3~4(76.2~101.6) 0.38 0.38
>4~7.1/2(101.6~190.5) 0.38 0.64
>7.1/2~9(190.5~228.6) 0.38 1.14

A179 / A192 T5 T11 T22 ASTM Carbon Steel Boiler Tubes

Applications:

1, For evaporator, heat exchangers, condensers, heat transfer equipment and similar pipes.

2, Widely used in the mechanical treatment field, petrochemical industry, transport and construction field

3, Ordinary structural purposes and mechanic structural purposes, for example in construction field, fulcrum bearing etc;

4, The transportation of fluids in the projects and big equipments, for example transport of water, oil, gas etc

5, Can be used in low and medium pressure boiler for the transportation of fluids, for example steam tube, big smoke tube, small smoke tube, generating tube etc
