LM311DR Integrated Circuit IC Chip Comparator General Purpose MOS Open Collector / Emitter TTL 8-SOIC
LM311DR Integrated Circuit IC Chip Comparator General Purpose MOS Open Collector / Emitter TTL 8-SOIC
Specifications
Brand Name :
Texas Instruments
Model Number :
LM311DR
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
50 pcs
Price :
negotiate
Payment Terms :
Western Union, T/T,Paypal
Supply Ability :
Consultation
Delivery Time :
2-3 working days
Packaging Details :
2500PCS/Standard Package
Type :
General Purpose
Output Type :
MOS, Open-Collector, Open-Emitter, TTL
Voltage - Supply, Single/Dual (±) :
3.5V ~ 30V, ±1.75V ~ 15V
Voltage - Input Offset :
7.5mV
Description

LM311DR Comparator General Purpose MOS Open-Collector Open-Emitter TTL 8-SOIC

Description:

The LM111, LM211, and LM311 are single high-speed voltage comparators. These devices are designed tooperate from a wide range of power-supply voltages, including±15-V supplies for operational amplifiers and5-V supplies for logic systems. The output levels are compatible with most TTL and MOS circuits. Thesecomparators are capable of driving lamps or relays and switching voltages up to 50 V at 50 mA. All inputs andoutputs can be isolated from system ground. The outputs can drive loads referenced to ground, VCC+ or VCC–.Offset balancing and strobe capabilities are available, and the outputs can be wire-OR connected. If the strobeis low, the output is in the off state, regardless of the differential input.

Type General Purpose
Number of Elements 1
Output Type MOS, Open-Collector, Open-Emitter, TTL
Voltage - Supply, Single/Dual (±) 3.5V ~ 30V, ±1.75V ~ 15V
Voltage - Input Offset (Max) 7.5mV @ ±15V
Current - Input Bias (Max) 0.25µA @ ±15V
Current - Output (Typ) -
Current - Quiescent (Max) 7.5mA
CMRR, PSRR (Typ) -
Propagation Delay (Max) -
Hysteresis -
Operating Temperature 0°C ~ 70°C
