Low Noise Plastic Bottle Moulding Machine With Touch Screen Long Life Span
Low Noise Plastic Bottle Moulding Machine With Touch Screen Long Life Span
Low Noise Plastic Bottle Moulding Machine With Touch Screen Long Life Span
Low Noise Plastic Bottle Moulding Machine With Touch Screen Long Life Span
Specifications
Place of Origin :
Jiangsu, China (Mainland)
Brand Name :
Reliable
Model Number :
RM-2000
Certification :
CE,ISO,SGS
Supply Ability :
15 Set/Sets per Month For Low Price Automatic PET Plastic Bottle Blow Moulding Machine
Packaging Details :
The normal packages is wooden box. If export to Europ Country,the wooden box will be after fumigated. If enter container the packages is too tighter,we may use PE film to wrapping the machine. or according customer special request. for Low Price Automat
MOQ :
1 Set/Sets
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Delivery Time :
25-35 working days
Product name :
Low Energy Automatic PET Plastic Bottle Blow Molding Machine For Water Production Line
Capacity :
2000-2500BPH
Operation :
Stable and easy
Control :
PLC and touch screen
Installation :
Available
Service :
Lifelong
Description

Low Energy Automatic PET Plastic Bottle Blow Molding Machine For Water Production Line

Brife Information

Automatic PET Plastic Bottle Blow Moulding Machine is suitable for blowing PET bottles of various shapes, volume from 100 ml to 2000 ml, wide application for blowing mineral water bottles, carbonated water bottles and juice bottles.

1. High Automatization

2. High Intelligence:The machine can be controlled through touch screen and running status is shown on it.

3. High Quanlity:Steady infrared heating system blowing and highly precise blow-mould closing system ensure quality.

4. No Contamination:Closed production zone, good self-lubrication system avoid contamination.

5. Low Cost:Low consumption of electricity, air and water.

6. High Transparency:Easy maintenance, absolute safely, visual inspection, low noise.

Technical Data

ITEM

RM-2000

RM-4000

RM-6000

Theoretical output

2000

4000

6000

Max.container volume

1.25L

1.25L

0.7L

Max.neck diameter

38MM

38MM

38MM

Max.container diameter

80MM

80MM

60MM

Max.container height

320MM

320MM

265MM

Number of cavity

2

4

6

Number of lamp

28

70

60

Max.heating power

42KW

84KW

90KW

Installation power

50KW

95KW

100KW

Actual power consumption

35KW

40KW

50KW

Operatating low pressure

0.7Mpa

0.7Mpa

0.7Mpa

Low pressure consuming

1400L/min

2000L/min

2000L/min

Blowing pressure

3.5Mpa

3.5Mpa

3.5Mpa

High pressure consuming

3500L/min

5000L/min

4500L/min

Operating pressure

0.3-0.5Mpa

0.3-0.5Mpa

0.3-0.5Mpa

Temperatuer

10

10

10

Flow rater

30 L/min

40 L/min

50L/min

Machine dimension

2.7×1.8×2.2

4×2×2.2

4.9×2.15×2.2

Machine weight

3500Kg

4800Kg

5000Kg

Machine Advantages

1> Energy saving

2> Easy to operate, just need feeding preform, other work is automatic.

3> Suitable for hot filling, PP, PET bottle blowing

4> Suitable for different preform neck size, it can change preform jigs very easily.

5> Mold replacement very easily.

6> Oven design in reasonable, adopt blowing-type, water cooling, air cooling all have. Suitable for hot environment to work, the preform neck can’t distortion.

7> The heating lamp adopt infrared quartz lamp, not easy to damager, it is different than semi-auto blowing machine lamp. So it no need frequently to change lamp. The lamp life is long, even it is broken, it can use also.

8> Our hand feeding stretch blow molding machine can add autoloader+manipulator to became fully automatic.

9> Our machine is more safety and stabilization.

10> Our clamping unit adopt clooked arm configuration self-lubricating system. So very stabilization and no noise.

Low Noise Plastic Bottle Moulding Machine With Touch Screen Long Life Span

Low Noise Plastic Bottle Moulding Machine With Touch Screen Long Life Span
