4 Cavity Mould Bottle Blow Molding Machine , Water Bottle Blowing Machine
4 Cavity Mould Bottle Blow Molding Machine , Water Bottle Blowing Machine
4 Cavity Mould Bottle Blow Molding Machine , Water Bottle Blowing Machine
4 Cavity Mould Bottle Blow Molding Machine , Water Bottle Blowing Machine
4 Cavity Mould Bottle Blow Molding Machine , Water Bottle Blowing Machine
4 Cavity Mould Bottle Blow Molding Machine , Water Bottle Blowing Machine
4 Cavity Mould Bottle Blow Molding Machine , Water Bottle Blowing Machine
4 Cavity Mould Bottle Blow Molding Machine , Water Bottle Blowing Machine
Specifications
Place of Origin :
Jiangsu, China (Mainland)
Brand Name :
Reliable PET Bottle Blowing Machine
Model Number :
RM-4000D
Certification :
CE ISO SGS TUV
Supply Ability :
15 Set/Sets per Month PET Bottle Blowing Machine
Packaging Details :
The normal packages is wooden box. If export to Europe Country ,the wooden box will be after fumigated. If enter container the packages is too tighter, we may use PE film to wrapping the machine. or
MOQ :
1 Set/Sets
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Delivery Time :
25-35 working days
Name :
PET Bottle Blowing Machine
Output :
4000BPH
Cavities :
4 Cavity Blowing Machine
Max Container :
2.0L
Processing Type :
Blow Molding Machine
Bottle Volume :
0.2-2L PET Bottle
Description

Fully Automatic Drinking Water PET Bottle Blow Molding Machine With 4 Cavity Mould

PET Bottle Blowing Machine ---Description

Blow Moulding Machines can blow the maximum capacity of the products is 2L. It can blow bottles in shapes: carbonated, mineral, pesticide, cosmetics, wide-mouth, hot filling, and other packing containers, which is made of plastic of crystalline type, such as PET and PP etc.
1).High Automatization
2).High Intelligence:The machine can be controlled through touch screen and running status is shown on it.
3).High Quanlity:Steady infrared heating system blowing and highly precise blow-mould closing system ensure quality.
4).High Speed:2000BPH(2-cavity),, 4000BPH(4-cavity), 6000BPH(6-cavity).
5).No Contamination:Closed production zone, good self-lubrication system avoid contamination.
6).Low Cost:Low consumption of electricity, air and water.
7).High Transparency:Easy maintenance, absolute safely, visual inspection, low noise.

Fully Automatic Drinking Water PET Bottle Blow Molding Machine With 4 Cavity Mould

PET Bottle Blowing Machine ---Technical Parameters

Model

RM-4000D PET Bottle Blowing Machine

Productivity

Depend on bottle design

3200-4000PCS/H

Product type

Body diameter

20mm-100mm

Height

50mm-350mm

Neck diameter

15mm-38mm

Mold

Cavity

4cavities

Mold thick

240mm

Mold

500*500mm

Main machine power

Electrical source power

380v 3Phase /220v 3Phase 50/60HZ

Rated Power

49kw

Really use power

14kw

Air source

LP air compressor

1.6m3/min 1.0MPa 1set (15KW)

HP air compressor

1.0m3/min 3.0MPa 2sets (each set 11KW)

Air dryer

2.0m3/min 3.0MPa 1set

Cooling water

Cooling water

15L/min

Size

L*W*H

1908*1858*1920mm

Weight

3600kg

preform unscrambler

L*W*H

2000*950*2480mm

Weight

250kg

Resin available

PET

Fully Automatic Drinking Water PET Bottle Blow Molding Machine With 4 Cavity Mould

PET Bottle Blowing Machine ---Brand

NO.

Parts name

Brand

The place of origin

1

Pneumatic components

AIRTAC

Taiwan

2

Turning cylinder

FESTO

German

3

High pressure air blowing valve

PARK

USA

4

Low pressure work valve

PMC

Korea

5

PLC controller

AELTA

Taiwan

6

Full computer screen

AELTA

Taiwan

7

High pressure muffler

ATOMUFFLER

USA

8

Oily water separator

AIRTAC

Taiwan

9

Photoelectric switch

AUTONICS

Korea

10

Switching power

AELTA

Taiwan

11

Circuit breaker

DELIXI

Wenzhou

12

Air switch

TAIAN

Taiwan

13

Relay

IDEC

Japan

14

Finger cylinder

AIRTAC

Taiwan

PET Bottle Blowing Machine ---Brief Introduction

Brief Introduction

Zhangjiagang Reliable Machinery Co., Ltd.Is a hi-tech designing and manufacturing enterprise, which is specialized in beverage production and packing complete lines as well as various water treatment machines.We are one of the earliest companies engaged in manufacturing liquid filling and packing equipment in China

Main Products

Liquid filling machines (water, fruit juice/tea, carbonated drink, oil, alcohol, plant protein drink, etc.), Barreled filling line(3-5 gallon) Water treatment machines, Labeling & packing machines, semi-automatic /full automatic bottle blowing machines, and injection molding machines.

Good Service

we also supply technique consultation, factory construction design plan, equipment installation and adjustment, technology training and other after-sales services.Now our products are exported to over ten countries and regions, including Southeast Asia, Russia, the Commonwealth of the Independent States, Western Asia and South Africa.

Payment

100%L/C at sight or T/T are both acceptable

Delivery Time

It is based on what kind of products you ordered, but usually it will take about 30 days after receiving your down payment and smaple bottles with caps.

Fully Automatic Drinking Water PET Bottle Blow Molding Machine With 4 Cavity Mould
