Eco Friendly Bottle Blow Molding Machine SUS 304 Stain Steel Material
Eco Friendly Bottle Blow Molding Machine SUS 304 Stain Steel Material
Eco Friendly Bottle Blow Molding Machine SUS 304 Stain Steel Material
Eco Friendly Bottle Blow Molding Machine SUS 304 Stain Steel Material
Eco Friendly Bottle Blow Molding Machine SUS 304 Stain Steel Material
Eco Friendly Bottle Blow Molding Machine SUS 304 Stain Steel Material
Specifications
Place of Origin :
Jiangsu, China (Mainland)
Brand Name :
Reliable Automatic Bottle Making Machine
Model Number :
RM-4000 Automatic Bottle Making Machine
Certification :
CE/SGS/ISO
Supply Ability :
10 Set/Sets per Month for 4 Cavity Used Blow Moulding Machine Price
Packaging Details :
Standard Wooden Packing or according to your reuqest
MOQ :
1 Set/Sets
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
25-35 working days
Application :
Bottle
Plastic Processed :
PET
Voltage :
380v or by your option
Capacity :
4000~4500 Bottles Per Hour
Cavities :
4 Cavities
Material :
SUS 304 Stain steel
Description

Full Automatic 4 Cavity Bottle Blow Moulding Machine For Soft Drink Bottle Making

1,New double crank four pull-up bar clamping structure, cross balance fixed slide

2,Sealing, stretch adapts parallel bars (CIS) design, combined, good for products molding

3,Advanced gas path design, single, dual air intake can be; low-pressure mechanical clamping, sealing, stretching; high pressure blowing molding

4,Programmable PLC controller automatically control, microcomputer touch screen convenient operation

5,Bottle embryo heated by infrared, controllable constant pressure control, so as to achieve the best blowing precision

ITEM

RM-A4

Theoretical output

4000

Max. container volume

1.25L

Max .neck diameter

38MM

Max. container diameter

80MM

Max. container height

320MM

Number of cavity

4

Number of lamp

70

Max .heating power

84KW

Installation power

95KW

Actual power consumption

45KW

Operating low pressure

0.7Mpa

Low pressure consuming

2000L/min

Blowing pressure

3.5Mpa

High pressure consuming

5000L/min

Operating pressure

0.3-0.5Mpa

Temperature

10

Flow rater

40 L/min

Machine dimension

4×2×2.2

Machine weight

4800Kg

low Moulding Machine Price

1.Pre-service
Guiding customers to choose the most suitable machine and give our suggestion.
Provide the workshop flow chart,machine photo,even machine video.
Specially designed for customer
It is better for you to send the samples to us before making machines.
2.Client visiting service
The nearest airport is:Shanghai Pudong International Airport or Wuxi Airport
We can go to pick you in Shanghai and we can also book the hotel for you in advance.
3.On-sale service
Tell customer about the production situation from time to time
Make preparation for customer and wait for checking at any time
Help customer to make their local customs clearance
4.After-sales service
Oversea install and training
Free maintenance and replacements of spare parts for free in 12 months,we promise
Provide electric drawing
Provide necessary spare parts for each machine which will be used in the future by DHL shipping
