150 Kg / H Capacity Auxiliary Equipment , Plastic Bottle Crushing Machine
150 Kg / H Capacity Auxiliary Equipment , Plastic Bottle Crushing Machine
150 Kg / H Capacity Auxiliary Equipment , Plastic Bottle Crushing Machine
150 Kg / H Capacity Auxiliary Equipment , Plastic Bottle Crushing Machine
150 Kg / H Capacity Auxiliary Equipment , Plastic Bottle Crushing Machine
150 Kg / H Capacity Auxiliary Equipment , Plastic Bottle Crushing Machine
150 Kg / H Capacity Auxiliary Equipment , Plastic Bottle Crushing Machine
150 Kg / H Capacity Auxiliary Equipment , Plastic Bottle Crushing Machine
Specifications
Brand Name :
Reliable
Model Number :
SPGL 18
Certification :
ISO SGS CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
15 sets per month
Delivery Time :
30-45 working days
Packaging Details :
Wooden package
Type :
LOW-SPEED GRANULATORS
Crushing chamber :
820*480*1225mm
Capacity :
150kg/h
Power :
2.2 KW
Application :
Waste Plastic material
Net Weigt :
168kg
Description

PET Plastic Bottle Crushing Machine Auxiliary Equipment For Plastic Recycling Machine

Feature

*18 SERIES LOW-SPEED GRANULATORS adopt new designed clawcutter. which don't need to adjust the gap between rotary cutter andstationary cutter after sharpening.

*Low rotating speed and the design of acute angle rotary cutter can make the crusher more stable.

*Material collecting tank cover the cutting chamber from outside to prevent material leakage.

*With perfect cutting angle.

*Low noise because of sound-proof hopper and low rotating speed.

*Easy to assemble and disassemble, to help easy maintainence.High safety standard,which applies to Europe safety standard.

Product Description

Our crusher is used for crushing all kinds of plastic, such as PP/PE film, plastic bags,woven bags,PET bottles, plastic HDPE PP bottle, buckets, containers, pellets plastic, sheets, ends from injection molding machines and extruder, etc

Technical parameter

SPGL modle

 1818 1830 1840 1840D

Rotating Speed

150 190

Rotary Cutter

18 30 42 6

Stationary Cutter

 2+2 4+2

Rotor Diameter(mm)

 180

Rotor Width(mm)

 180 300 400

Crushing Chamber(mm)

 270*180 270*300 270*400

Power(kw)

 2.2 3.0

Net Weight(kg)

 168 200 220 210

Dimension(LXWXH ) mm3

 820*480*1225 970*480*1260 1090*1090*1360
