Large Capacity 68KW Fully Automatic Pet Bottle Blowing Machine Long Life Time
Large Capacity 68KW Fully Automatic Pet Bottle Blowing Machine Long Life Time
Large Capacity 68KW Fully Automatic Pet Bottle Blowing Machine Long Life Time
Large Capacity 68KW Fully Automatic Pet Bottle Blowing Machine Long Life Time
Large Capacity 68KW Fully Automatic Pet Bottle Blowing Machine Long Life Time
Large Capacity 68KW Fully Automatic Pet Bottle Blowing Machine Long Life Time
Large Capacity 68KW Fully Automatic Pet Bottle Blowing Machine Long Life Time
Large Capacity 68KW Fully Automatic Pet Bottle Blowing Machine Long Life Time
Specifications
Brand Name :
Reliable
Model Number :
RM-2000
Certification :
CE ISO SGS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1 Set/Sets
Price :
26000-27000 USD/set
Payment Terms :
L/C, T/T
Supply Ability :
15 Set/Sets per Month Automatic Used PET Bottle Stretch Blowing Molding Machine
Delivery Time :
35-45 working days
Packaging Details :
The normal packing is wooden box
Power(W) :
68KW
Weight :
4600KG
Capacity :
2000BPH/500ml bottle
Application :
Bottle,PET bottle making machine
Condition :
New
Plastic processed :
PET
Description

2019 Newest Design Equipment Automatic PET Bottle Blowing Machine / Machinery

We can help you design a bottle as long as you tell us the height, diameter, and material of the bottle

Machine Procedures

Step 1. Put the preform into preform container and the conveyer will take the preform to orientation units automatically.

Step 2. Load the preform at neck up to preform holder, and then preform is conveyed into baking tunnel.

Step 3. After heating, preform is conveyed into the blow station, then close the mold, stretch and blow under low pressure and high pressure, exhaust, open the mold.

Step 4. The finished bottle is taken off by automatic discharging system

Machine Features

  • Energy saving
  • Easy to operate, just need feeding preform, other work is automatic.
  • Suitable for hot filling, PP, PET bottle blowing
  • Suitable for different preform neck size, it can change preform jigs very easily.
  • Mold replacement very easily.
  • Oven design in reasonable, adopt blowing-type, water cooling, air cooling all have. Suitable for hot environment to work, the preform neck can’t distortion.
  • The heating lamp adopt infrared quartz lamp, not easy to damager, it is different than semi-auto blowing machine lamp. So it no need frequently to change lamp. The lamp life is long, even it is broken, it can use also.
  • Our hand feeding stretch blow molding machine can add autoloader+manipulator to became fully automatic.
  • Our Blow Moulding Bottle Machine is more safety and stabilization.
  • Our clamping unit adopt clooked arm configuration self-lubricating system. So very stabilization and no noise.

Machine Parametre

Model RM-500 RM-2000 RM-4000 RM-6000
Clamping force 150KN 180KN 370KN 565KN
Clamping stroke 120-175MM 120-175MM 120-175MM 80-130MM
Number of cavities 1Cavity 2Cavity 4Cavity 6Cavity
Theoretical output 1000BPH 2000BPH 4000BPH 6000BPH
Max.mould thickness 250MM 250MM 250MM 300MM
Total power 20KW 28KW 60KW 75KW
Max.container volume 6L 1.5L 1.5L 1.5L
Neck diameter range 16-38mm 16-38mm 16-38mm 16-38mm
Max.container diameter 110mm 110mm 110mm 110mm
Max.container height 380mm 380mm 380mm 360mm
