Specifications
Brand Name :
Reliable
Model Number :
RM-4000
Certification :
CE ISO SGS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1 Set/Sets
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
15 Set/Sets per Month Automatic Used PET Bottle Stretch Blowing Molding Machine
Delivery Time :
35-45 working days
Packaging Details :
The normal packing is wooden box
Blow Moulding Type :
Stretch Blow Moulding
Voltage :
380V/3PH/50HZ
Power(W) :
70KW
Weight :
4500KG
Capacity :
4000BPH
Control :
PLC+Touch Screen
Application :
PET bottle making machine
Plastic processed :
PET
Description

Best Choice Blow Moulding PET Bottle Blowing Machine For Water Bottle

Description

RM Blow Moulding Equipment can blow the maximum capacity of the products is 2L. It can blow bottles in shapes: carbonated, mineral, pesticide, cosmetics, wide-mouth, hot filling, and other packing containers, which is made of plastic of crystalline type, such as PET and PP etc.
1).High Automatization
2).High Intelligence:The machine can be controlled through touch screen and running status is shown on it.
3).High Quanlity:Steady infrared heating system blowing and highly precise blow-mould closing system ensure quality.
4).High Speed: 2000-6000BPH(2,4,6-cavity).
5).No Contamination:Closed production zone, good self-lubrication system avoid contamination.
6).Low Cost:Low consumption of electricity, air and water.
7).High Transparency:Easy maintenance, absolute safely, visual inspection, low noise.

Characteristics:

1:Multi screen for choice, dynamic picture display with Chinese/English ,change or extend program according to client request
2:five-step mold closing, four-step mold opening; two-step carriage forward or retracting
3:World famous electrical components and high quality circuit hardware with stable and reliable running
4:Imported computer special for injection molding machine with multiple functions and precise control processing
5:point twin toggle clamping system by modular optimization software designing. Strong clamping with rapid and stable, to meet the strict clamping condition
6:Mould height adjustment by hydraulic driven gear system with rapid and stable
7:Nitrided screw and barrel with long service life.....
8:Transducer control clamping stroke and injection stroke to accuracy of ±0.05mm.

Technical Data:

ITEM
RM-2000
RM-4000
RM-6000
Theoretical output
2000
4000
6000
Max.container volume
1.25L
1.25L
0.7L
Max.neck diameter
38MM
38MM
38MM
Max.container diameter
80MM
80MM
60MM
Max.container height
320MM
320MM
265MM
Number of cavity
2
4
6
Number of lamp
28
70
60
Max.heating power
42KW
84KW
90KW
Installation power
50KW
95KW
100KW
Actual power consumption
35KW
40KW
50KW
Operatating low pressure
0.7Mpa
0.7Mpa
0.7Mpa
Low pressure consuming
1400L/min
2000L/min
2000L/min
Blowing pressure
3.5Mpa
3.5Mpa
3.5Mpa
High pressure consuming
3500L/min
5000L/min
4500L/min
Operating pressure
0.3-0.5Mpa
0.3-0.5Mpa
0.3-0.5Mpa
Temperatuer
10
10
10
Flow rater
30 L/min
40 L/min
50L/min
Machine dimension
2.7×1.8×2.2
4×2×2.2
4.9×2.15×2.2
Machine weight
3500Kg
4800Kg
5000Kg
