Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine
Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine
Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine
Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine
Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine
Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine
Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine
Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine
Specifications
Brand Name :
BAISU / SUNRAY
Model Number :
Double Station EBM SRB70D-2
Certification :
CE / ISO9001
Place of Origin :
ZHANGJIAGANG, JIANGSU
MOQ :
1 Set
Price :
USD 28500-30000 / Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 Sets/ Year
Delivery Time :
60 Days
Packaging Details :
Covered with water-proof film, fastened with special container loop and hooks.
Machine Type :
Automatic Extrusion Blow Molding Machine
Product Range :
Ocean ball, toy ball, plastic balls
Max Volume :
2L
Material :
LDPE
Capacity :
1800 Pcs/hour
Power Avg. :
32.5 KW
Platen Size :
320x390 mm
Guarantee :
1 Year
Description

Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine, Plastic Toy Ball Automatic Extrusion Blow Molding Machine, LDPE Toy Balls Making Machine

QUICK VIEWS

1. SRB70D-2 is double station double head plastic products making machine, specially for LDPE ocean balls.

2. The output for Dia.65~85mm ocean ball is 1800 Pcs/hour, the daily production capacity is 43200 balls.

3. Machine total control system with 100 point parison thickness controller to better parison thickness distribution.

4. Aluminum cantilever box, product guidance shelves, scraps sliding channels to convenient actual production.

TECHNICAL PARAMETERS

Machine Model Double Station Extruder Blowing Machine
Max Product Volume 2 L
Machine Weight 5.5 Tons
Machine Size 3.8 x 2.2 x 2.5 m
Screw Diameter 70 mm
Plasticizing Capacity 90 KG
Clamping Force 68 KN
Platen Size 320 x 390 mm
Platen Opening Stroke 150~500 mm
Max Mould Size 360 x 360 mm
Double Head Central Distance 160 mm
Max Product Diameter or Width 135 mm
Material Cutting Method Hot Cutting
Max Die Diameter 100 mm
Total Power 48.5 KW
Average Energy Consumption 31.5 KW

Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine

Click picture above to see SRB70D-2 production video for ocean balls

MACHINE ADVANTAGES

1. Our continuous extrusion blow moulding machines cover 0~30L bottles, jerry cans, jars, containers, kettles, small toys, pipes and other hollow articles. Based on your capacity requirement, we can adopt single head, double head, triple head, four head and six head with good material runner design.

2. According to your demand of packing objects and cost control, our machine can be made with co-extrusion of 2~4 layers and view stripe line. The design concept of us to 0~30L machine is stable working performance, fast production speed, higher automatic degree and lower fault rate.

3. Total machine control system well match with scraps on-line deflashing, neck rotary cutting, in-mould labeling, leakage testing, product conveying & packing. Optimized hydraulic system with reasonable design to control pressure and flow of double proportion, acchieve action execution fast, stable and accurate. High hardness bimetallic screw with good structure design and modulation, insure bigger plasticizing capacity, less wearing and longer working lifespan.

4. Rich experience in whole producing line arrangement and layout, totally automatic running from material feeding to finished product packing. Colorful touch screen, aluminum cantilever operation box, bottle collective guidance shelves, scraps sliding channel and safety protection are included.

PRODUCTION ARRANGEMENT

1. Machine Foundation Size: 3.5 x 2 m

2. Production Area: 7 x 5 m

3. Minimum Workshop Height: 3.0 m

4. Air Supply Requirement: 1.0m3/min, 0.6Mpa

5. Water Supply Requirement: 8 Tons

6. Machine Power Consumption: 32.5 KW

7. Production Line Power Consumption: 45 KW

8. Whole Line Electricity Arrangement: 250 Amps

9. Minimum Workers Number: 2 Workers

Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine

Plastic Products Making Machine LDPE Plastic Toy Ball / Ocean Ball Making Machine
