Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity
Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity
Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity
Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity
Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity
Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity
Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity
Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity
Specifications
Brand Name :
BAISU / SUNRAY
Model Number :
350L EBM SRB120N
Certification :
CE / ISO9001
Place of Origin :
ZHANGJIAGANG, JIANGSU
MOQ :
1 Set
Price :
USD 115000-125000 / Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 Sets / Year
Delivery Time :
90 Days
Packaging Details :
Covered with water-proof film, fastened with special container loop and hooks.
Machine Type :
Plastic Blow Moulding Machine
Product Range :
Buoy, Plastic Floating Pontoons, Floater
Max Volume :
350L
Material :
HDPE
Capacity :
12-18 Pcs/hour
Power Avg. :
95 KW
Platen Size :
1400x1600 mm
Guarantee :
1 Year
Description

Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity, 350L Plastic Container Making Machine, HDPE Floating Buoy and Dock Extrusion Blow Moulding Machine

QUICK VIEW

1. SRB120N is special extrusion blow molding machine for plastic floaters, pontoons, buoy and dock.

2. Its output for 7KG cubic pontoon is 16 Pcs/hour, for 13KG double cubic pontoon is 14 Pcs/hour.

3. Energy saving, mature hydraulic and electric design, low problem rate to reduce your production cost.

MACHINE PARAMETERS

Machine Model Fully Automatic Blow Moulding Machine
Max Product Volume 350 L
Machine Weight 26.5 Tons
Machine Size 7.8*4.3*6.2 m
Screw Diameter 120 mm
Plasticizing Capacity 360 Kg/hour for HDPE
Clamping Force 1500 KN
Platen Size 1400*1600 mm
Platen Opening Stroke 800-1800 mm
Max Mould Size 1250*1800 mm
Accumulating Volume 30 L
Max Ejection Weight 22.5 Kg
Max Product Weight 12.5 Kg
Max Die Diameter 850 mm
Total Power 195 KW
Average Energy Consumption 95 KW

Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity

PRODUCTION ARRANGEMENT

1. Machine Size: 7.8x4.3x6.2 m

2. Production Area: 15 x 10 m

3. Minimum Workshop Height: 7 m

4. Air Supply Requirement: 1.6m3/min, 0.8Mpa

5. Water Supply Requirement: 20 Tons

6. Machine Power Consumption: 95 KW

7. Production Line Power Consumption: 130 KW

8. Whole Line Electricity Arrangement: 800 Amps

9. Minimum Workers Number: 3 Workers

MACHINE FEATURES

1. SRB120N is fully automatic accumulating blow molding machine for 350L as maximum.

2. HDPE recycled material special screw with high hardness bimetallic alloy.

3. extrusion system is driven by 6 grade motor for plastcizing capacity 360KG.

4. 30L vertical type FIFO accumulating head for max ejection weight 22.5KG.

5. Clamping unit can be pushed outward with oil cylinder, easy for changing moulds.

6. High speed total machine control system with 100 point parison thickness controller.

7. PHASE servo motor & SUMITOMO gear pump for energy saving and control oil temp.

8. Height adjustable bottom blowing unit & parison expanding unit, motor-dring water chilled robot arm.

OTEHER DETAILS

1. Our accumulating extrusion blow molding machines covers 30~1000L drums, tanks, containers, pallets and toys.

2. High hardness bimetallic screw has 12 years lifespan for new material & 8 years for recycled material.

3. Servo motor system and gear pump are used in optimized hydraulic system, saving your energy consumption.

4. Integrated machine control, , saving 20 moulds’ formula, 100 point parison thickness control.

5. For large products, we use 1+2 hydraulic cylinder structure to insure clamping effect also moving speed.

6. For abnormal shaped products, we can provide individulized blow molding machine for your wanted technics.

7. Rich experience in whole producing line layout and working flow arrangement, highten your production effeciency.

Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity

Plastic Floating Pontoon Blow Molding Machine 12 BPH Capacity
