Specifications
Brand Name :
BIEVO
Model Number :
DGF12-6
Certification :
CE, ISO 9001:2008
Place of Origin :
China,Jiangsu
MOQ :
1set
Price :
20000dollers/set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10 sets per month
Delivery Time :
20-30working days
Packaging Details :
wood case
Type :
Beer filling machine
Automatic Grade :
Automatic
Material :
SUS 304
Voltage :
220V / 380V / 415V
Dimension(L*W*H) :
2200X2100X2200MM
Weight :
2500KG
Filling Material :
Beer /carbonated drinks
Filling Valve Head :
Multi-Head
Bottle Shape :
Cans /glass bottle
Core Components :
Pump, PLC
Filling Accuracy :
99.9%
Condition :
New
Key Selling Points :
Full automatic
Bottle Size :
200ml-1000ml (Customized)
Function :
Cans filling sealing machine
Control System :
Plc+touch screen
Workshop Layout :
Free Design
Application :
Beverage
Packaging Material :
Wood
Driven Type :
Electric
Machinery Capacity :
1500bph
Description

Automatic 330ml Craft Beer Beverage Juice Aluminum Cans Filling Sealing Machine

This combination machine is suitable for the filling and sealing of beer and beverage industry.This combination machine is filled with single room pressure filling valve, which can not be used in the filling process.The seal is a double winding edge spinning and frequency control control.Are characterized by their smooth filling, large flow, speed, filling quantity allowed, no tank filling, dripping, cylinder depth of the liquid level automatic control, material cylinder can be automatic cleaning disinfection,the characteristics of the production speed is adjustable, suitable for filling and sealing all kinds of cans.
Filling part
<1> 304/316 Stainless steel high precision filling nozzle
<2> Filling volume adjustable in fine rank, same liquid level after filling
<3> All 304/316 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean
<4> 304/316 stainless steel filling pump
<5>Efficient spray nozzle rinse thoroughly and save water for flushing
Capping part
<1> Place and capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping
<2> All 304/316 stainless steel construction
<3> Automatic stop when lack of bottle
<4>Capping effect is stable and reliable ,Defective rate ≤0.2％ .
Flat conveyor
<1>Energy saving. High efficient. Adapt to customer factory layout
<2>Special lubrication system, keep products clean, health, safety
<3>Extended service life
<4>Electric eyes design keep whole line running safety and quickly
<5>Overload protection mechanism to effectively ensure the safety of the machine

Product Paramenters:

Model
DYGF12-2
DYGF18-4
DYGF24-4
Amoust of working position
filling 12, sealing 2
filling 18, sealing 4
filling 24, sealing 4
Production Speed
3000CPH(330ml)
6000CPH
10000CPH
Pressure of rinse water
0.06~0.2Mpa
0.06~0.2Mpa
0.06~0.2Mpa
Main motor power
2.87kw
3.12kw
3.92kw
Dimension(L*W*H)mm
2.7*2.3*2.7(L*W*H)
2.8*2.6*2.7(L*W*H)
2.95*2.6*2.7(L*W*H)
Weight
3500kg
4750kg
6000kg

330-1000ml Beer Can Filling Machine 415V Tin Can Filling Machine

330-1000ml Beer Can Filling Machine 415V Tin Can Filling Machine

330-1000ml Beer Can Filling Machine 415V Tin Can Filling Machine

330-1000ml Beer Can Filling Machine 415V Tin Can Filling Machine

330-1000ml Beer Can Filling Machine 415V Tin Can Filling Machine

S/N Name Brand Country
1 Main motor ABB Switzerland
2 Inverter MITSUBISHI Japan
3 PLC OMRON Japan
4 Touch screen MITSUBISHI Japan
5 Contactor SCHNEIDER France
6 Thermo- relay SCHNEIDER France
7 Air-break switch SCHNEIDER France
8 Proximity switch TURCK USA
9 Photoelectric switch BANNER USA
10 Air circuit system SMC Japan
11 Water pump Southern Japan

330-1000ml Beer Can Filling Machine 415V Tin Can Filling Machine

330-1000ml Beer Can Filling Machine 415V Tin Can Filling Machine

330-1000ml Beer Can Filling Machine 415V Tin Can Filling Machine

Zhangjiagang City Bievo Machinery Co., Ltd. is located in a national level development zone - Zhangjiagang Economic And Technology Development Zone, covering area more than 8,000 square meters.We enjoy convenient transportation with Shanghai Hongqiao International Airport and Shanghai Pudong International Airport on hand.Which accumulated a great number of China's top technologists in the liquid beverage industry.We have complete system from designing, manufacturing, installation, training to after service.Our main product water production line, carbonated beverage production line . Fruit juice and milk production line ,3 to 5 gallons production line, daily chemical production line and so on.Plat and tube UHT device, CIP system.All the products are sold well.We devote ourselves to the development, research and production of liquid food and beverage filling and packing industry .

330-1000ml Beer Can Filling Machine 415V Tin Can Filling Machine

330-1000ml Beer Can Filling Machine 415V Tin Can Filling Machine

1. A: Are you factory?How many workers do you have?

B: Yes,we are factory. our factory is located in zhangjiagang near from shanghai. We have about 50 workers in our factory.
2. A: What about after sale service?
B: 12months of electrical part and 18months of mechanical part after machine installed and running normally.
3. A: What about installation?
B: Our engineer can be sent to your country. but customer should pay the air tickets and 100usd as salary per person per day. besides, customer should arrange the accommodation for them during the trip.
4. A: What do we do if we encounter problem about the machine ?
B: Show us the picture or video of the problem. If the problem is from small machine, we will send you solution by video. If the problem is from large machine, our engineer will go to your factory (customer will pay the fee during the trip).
5. A: How can you control the quality and delivery?
B: All our machines will be tested before packaging. wooden packaing is strong and safety for long delivery.
330-1000ml Beer Can Filling Machine 415V Tin Can Filling Machine

<1>Installation, debug
After equipment reached the workshop of customer, place the equipment according to plane layout we offered. We will arrange seasoned technician for equipment installation, debug and test production at the same time make the equipment reach the rated producing capacity of the line. The buyer need to supply the round tickets and accommodation of our engineer, and the salary.

<2>Training
Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. Seasoned technician will guide and establish training outline. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.

<3>Quality guarantee
We promise that our goods are all new and not used. They're made of suitable material, adopt new design. The quality, specification and function all meet the demand of contract. We promise that the products of this line could storage for one year without adding any aseptic.
