5 Gallon Water Machine Barrels Washing Filling Capping Machine 3 In 1 1200kg
5 Gallon Water Machine Barrels Washing Filling Capping Machine 3 In 1 1200kg
5 Gallon Water Machine Barrels Washing Filling Capping Machine 3 In 1 1200kg
5 Gallon Water Machine Barrels Washing Filling Capping Machine 3 In 1 1200kg
Specifications
Brand Name :
JIAYUAN
Model Number :
QGF-300
Certification :
CE,ISO,SGS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1piece
Price :
US $30,000 - 50000 / Set
Supply Ability :
10 Set/Sets per Month
Delivery Time :
30 working days
Packaging Details :
wooden box
Material :
stainless steel 304
Condition :
New
Application :
Beverage, Food, Medical
Packaging Type :
Barrel,Bottles, Cartons
Packaging Material :
Paper, Plastic, Wood
Automatic Grade :
Automatic
Driven Type :
Electric
Power :
3.8kw
After-sales Service Provided :
Engineers Overseas Service
Warranty :
12 months for free
Power supply :
380V/50HZ(adjustable)
Filling type :
Normal pressure filling
Processing Types :
Water
Dimension(L*W*H) :
3800*1300*1600MM
Filling bottle size :
3-5gallen/3-19L
Weight :
1200kg
Description

5 gallon barrels washing filling capping machine production line

Product Description
5 gallon barrels washing filling capping machine production line

Keyword: Filling Machine/5 gallon Washer Filler Capper Monobloc/5 gallon production line/5 gallon rinsing filling capping/5 gallon barreled production line

Barreled drinking water production line

5 gallon barrels washing filling capping machine production line

1.It has the following types:80 type,100 type,150 type,300 type,450 type,600 type,900 type.

2.It integrates bottle washer, filler and sealer into one unit. In order to achieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and bleaching are used in bottle washer,washing solution can be used circularly.

3.The sealer can seal barrel caps are aseptic and healthy,this line can also automatically carry out washing,sterilizing,filling, capping, counting and products discharging.It is a new kind of barreled water auto-producing line,which integrates mechanism, electricity and pneumatic technologies together.

Model QGF-80 QGF-150 QGF-300 QGF-450 QGF-600
Filling heads 1 1 2 3 4
Volume 18.9 18.9 18.9 18.9 18.9
Barrel size 270*490 270*490 270*490 270*490 270*490
Capacity 80 150 300
Gas pressure 0.4 -0.6 0.4 -0.6 0.4 -0.6 0.4 -0.6 0.4 -0.6
Gas consumption 0.37 0.37 0.6 0.8 1
Motor power 1.38 1.75 3.8 3.8 7.5
Motor voltage 380V/50HZ 380V/50HZ 380V/50HZ 380V/50HZ 380V/50HZ
Weight 500 700 1200 1600 2000
Dimension 2500*1100*1600 2800*1100*1600 3800*1300*1600 4200*1600*1600 4800*1800*1600

5 Gallon Water Machine Barrels Washing Filling Capping Machine 3 In 1 1200kg

Our Services

1.One year warranty for the whole system.

2.Free equipment installation and debugging.

3.After one year, we can help you to maintain the machine and the accessories are provided only one the cost price.

4.We can provide internship service and help you train the operator and mechanic.

5.Free beverage production technology and process configuration.

6We can help you to design the product line, workshop and provide turn-key project.

5 Gallon Water Machine Barrels Washing Filling Capping Machine 3 In 1 1200kg

Company Information

Jiayuan company was established in1997,and for years we have been focusing on the improvement in machinery theory and performance in the food machinery industry.we have such as CE,ISO etc certification.we are a company integrating scientific research,production and service,and have the best manufacturing facilities and production process,professional staffs,imported facilities of concentration distill series,automatic CIP series,PLC control etc.Now we have been a market leader in the Chinese food machinery industry.The company keeps in mind the tenet of "serving users" and focus on research and development of new technologies.It has comprehensive development capacity and sound quality assurance system,and has made R&D achievement and obtained invention patents.Our machinery are widely sold in China,and exported over 20 countries,adn gained favorable feedback from users.Our major engineering projects include complete dairy products production line,beverage production line,biochemical engineering production line.
