Specifications
Brand Name :
Jiayuan
Model Number :
QS-12; CYG-12; FXZ-1
Certification :
CE,SGS
Place of Origin :
China Mainland
MOQ :
1 set
Price :
USD8500-100000
Payment Terms :
T/T; L/C
Supply Ability :
10 sets/month
Delivery Time :
20 days
Packaging Details :
Wooden case for shipment
condition :
new
Automatic Grade :
Auto
Bottle type :
Glass Bottle
material :
stainless steel 304
Feature :
high speed
service :
top service
warranty :
1 year
filling material :
flow liquid
Description

Long Life Auto juice beverage production line/juice production line machine

Description:

JUICE MACHINE PROFILE

Standard 3-in-1 monoblock for PET bottles rinsing, hot filling and capping. It is applicable to fruit juice, tea beverage, functional beverage, etc with 2000-20000BPH capacity. According to the special production condition, another sterilizing rinsing module could be added, that is 4-in-1 monoblock. The system has fully considered the beverage's characteristics (such as the frothing of the tea drink and mixed juice) and the technical requirement of the hot filling.

Long Life Auto Juice Beverage Filling Line For Food Industry Juice Production

RINSING SECTION

Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180° along the conveying rail. There are two times of internal and external washing, the efficiency of bottle washing is high.

Rinsing machine adopts original overturn and double-opened bottle clip. Bottle clip lock the bottleneck, the material of bottle clip is SUS304, which is hygienic and durable.

Bottle clip equipped with efficient spray on nozzle. The extrusive droplet with 15° angle ensures to wash all side of the bottle, and can save the water.

FILLING SECTION

The design of filling structure is reasonable and hygiene dead angle, the run of equipment is stable, it can control the material from the bottleneck, the control accuracy is within ±2mm.

The filling valve material is SUS304

The filling system has liquid level automatic control.

Filling valve lift is controlled by the valve elevator, after filling valve contact the bottleneck ,it start to fill.

Bottle is conveying by the wheel in the filling part.

The juice or other hot beverage can be backflow by return tank to control filling temperature.

CAPPING SECTION

Screw capping machine is most precision part in the 3-1 machine, it has a big influence to the goods stability and defective rate. Our screw capping has following feature.

Technique parameters:

Model RCGFB16-16-16-6 RCGFB24-24-24-8 RCGFB40-40-40-12
Bottle washing head 16 24 40
Pulp filling head 16 24 40
Juice filling head 16 24 40
Cap screwing head 6 8 12
Rated production capacity 4000BPH 8000BPH 15000BPH
Installed capacity 3.8KW 6.5KW 9.5KW
Overall size 3050*2000*2400mm 4070*2350*2400mm 6250*3050*2400mm

Service

1.Installation

After equipments reached the workshop of customer, place the equipments according to plane layout we offered. We will arrange seasoned technician for equipments installation, debug and test production at the same time make the equipments reach the rated producing capacity of the line. Time for installation and debug is 15-25 days.

2.Training

Our company offer technology training to customer. The content of training is structure and maintenance of equipments, control and operation of equipments. Training is in the workshop of customer. Seasoned technician will guide and establish training outline. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.

3.Quality Guarantee

We promise that our goods are all new and not used. They’re made of suitable material, adopt new design. The quality, specification and function all meet the demand of contract. We promise that the products of this line could storage for one year without adding any aseptic.

Industry Application
Electronic industrial Cleaning water of electronic components (Integrated circuits, silicon chips, display tube, electrode foil
pharmaceutical industry Transfusion, injections, tablets, biochemical products, equipment cleaning, etc.
Chemical industry chemical recycling water,chemical products manufacturing,chemical fertilizer
Electric power industry,Boiler Feed water Thermal power boiler, low pressure boiler power system in factories and mines
Food industry Pure drinking water, beverages, beer, wine, health products
Seawater, brackish water desalination Island, ships, offshore drilling platforms, brackish water
Drinking water Estate, communities, enterprises
Others Grey water reuse, coated glass, fine chemicals, printing and dyeing
