Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment
Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment
Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment
Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment
Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment
Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment
Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment
Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment
Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment
Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment
Specifications
Brand Name :
jiayuan
Model Number :
RCGF
Certification :
CE,SGS
Place of Origin :
CHINA,MAINLAND
MOQ :
1 set
Price :
USD 16000 -55000 set
Payment Terms :
T/T
Supply Ability :
15 sets per month
Delivery Time :
15 work days
Packaging Details :
wooden case
certification :
CE,SGS
water consumption :
1600kg/h
power :
6.68kw
weight :
3000kg
dimension :
2450*1800*2200
warranty :
1year
Description

SUS304 Silvery White Wine/Juice Filling Machine 6000bph PCl Control+Touch Screen​

Introduction:

The equipment is used for the production of wine, alcohol drink,mineral water, pure water, juice, etc.

It integrates washing ,filling ,capping together.The design is scientific and reasonable ,It's oppearance is beautiful ,operation and maintentic is convenient.

Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment

Parameter

Model RCGF16-12-6 RCGF24-24-8 RCGF32-32-10
Production capacity(500ml)(b/h) 3000 10000 14000
Filling precision ≤±5MM(Liquid Level) ≤±5MM(Liquid Level) ≤±5MM(Liquid Level)
Feedback consumption ≤10% ≤10% ≤10%
Polyester bottle standard(mm) (BottleDiameter)50-92;(Height):150-310 (BottleDiameter)50-92;(Height):150-310 BottleDiameter)50-92;(Height):150-310
Suitable cap shape (Plastic Screw Cap) (Plastic Screw Cap) (Plastic Screw Cap)
Water pressure of washing bottle(Mpa) 0.18 0.18 0.18
Wash pressure of washing bottle(kg/h) 800 2500 3500
Gas sourse pressure(Mpa) 0.6 0.6 0.6
Gas consumption(m3/min / 0.4 0.5
Total power 5.88 7.68 9.18
Total weight 2500 4000 5000
Dimensions(L*W*H)(mm) 2100×1500×2200 2750×2180×2200 3600×2800×3150

Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment

Washing part

Rotary pan is made of stainless steel 304.The rubber clamp splice seizes the mouth of bottles, which is fixedness and reliable.

Filling part

The way of filling is gravitation filling. The filling valve is adopted best stainless steel 304.The structure of filling valve is reasonable, the amount is correct.When filling the bottle, the bottle is move but the valve is stationary. The splint of bottle-neck seizes mouth of bottles.

Capping part

The dropping cap guide track fixes the device which can protect the cap from turning over and also set the device which can take out the inverse cap, equip a photo electricity switch which can stop the machine when lacking the cap and also avoid the situation that there is bottle without cap. The bottle inlet switch which is set in the capping machine, with the locking cap which is the connection of the dripping cap guide track and dialing cap pan controls the discharging of cap.

Fruit Juice Processing Juice Filling Machine , PCL Touch Screen Bottling Juice Equipment

Our Service

1) One year warranty for the whole system.

2) Free equipment installation and debugging.

3) After one year, we can help you to maintain the machine and the accessories are provided only one the cost price.

4) We can provide internship service and help you train the operator and mechanic.

5) Free beverage production technology and process configuration.

6) We can help you to design the product line, workshop and provide turn-key project.

Company Information
Zhangjiagang Jiayuan Machinery Co., Ltd. is located in Zhangjiagang city, which is near to Shanghai. We professionally research, develop and manufacture beverage packaging machines. We are a high technology enterprise of Jiangsu Province, and the best supplier of China beverage packaging machinery area. We are dedicated to the most advancement technology of beverage packaging machinery, and have always been conducting good up-to-date technical communication and exchange with leading Italy, Germany, France packaging companies. We have a strong technology team for beverage packaging machines’ manufacture. We provide marketing analysis, project budget, equipment technical configuration, and training for operator etc.
