5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM
5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM
5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM
5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM
5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM
5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM
5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM
5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM
Specifications
Brand Name :
JIAYUAN
Model Number :
QGF-150
Certification :
CE,ISO,SGS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1piece
Price :
US $30,000 - 50000 / Set
Supply Ability :
10 Set/Sets per Month
Delivery Time :
30 working days
Packaging Details :
wooden box
Material :
Stainless steel 304
Driven Type :
Electric
Warranty :
1 year for free
Filling type :
Normal pressure filling
Processing Types :
Water
Dimension(L*W*H) :
2800*1100*1600MM
Filling bottle size :
1-5gallen/3-19L
Weight :
700kg
Description

5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM

150BPH 5 gallon water washing filling capping machine

1.It has the following types:80 type,150 type,300 type,450 type,600 type,900 type.

2.It integrates bottle washer, filler and sealer into one unit. In order to achieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and bleaching are used in bottle washer,washing solution can be used circularly.

3.The sealer can seal barrel caps are aseptic and healthy,this line can also automatically carry out washing,sterilizing,filling, capping, counting and products discharging.It is a new kind of barreled water auto-producing line,which integrates mechanism, electricity and pneumatic technologies together.

Features

(1) This filling line specially produces 3&5 gallons barreled drinking water.

(2)This series barreled filling production line integrates bottle washer, filler and sealer into one unit.

(3) In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. The sealer can seal bottle caps automatically.

(4) This filling line equips with water spraying device to sterilize caps of bottles in order toensure those caps are aseptic and healthy.

(5) This line also can automatically carry out bottle washing, sterilizing, filling, capping, counting and products discharging.

(6) It has features of complete functional, novel design, and high degree of automation. It is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.

(7) Advanced PLC control system

(8) The key parts are imported and their quality is reliable.

(9) Barreled water production line machine is made of stainless steel.

(10) Its structure is reasonable and its operation is convenient.

(11) Easy cleaning and corrosion.

Technical parameter

Model QGF-80 QGF-150 QGF-300 QGF-450 QGF-600
Filling heads 1 1 2 3 4
Volume 18.9 18.9 18.9 18.9 18.9
Barrel size 270*490 270*490 270*490 270*490 270*490
Capacity 80 150 300
Gas pressure 0.4 -0.6 0.4 -0.6 0.4 -0.6 0.4 -0.6 0.4 -0.6
Gas consumption 0.37 0.37 0.6 0.8 1
Motor power 1.38 1.75 3.8 3.8 7.5
Motor voltage 380V/50HZ 380V/50HZ 380V/50HZ 380V/50HZ 380V/50HZ
Weight 500 700 1200 1600 2000
Dimension 2500*1100*1600 2800*1100*1600 3800*1300*1600 4200*1600*1600 4800*1800*1600

5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM

5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM

5 Gallon Pet Bottle Filling Machine / 20 Liter Mineral Water Bucket Plant 2800*1100*1600MM

Our Services

1. One year warranty for the whole system.

2. Free equipment installation and debugging.

3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price.

4. We can provide internship service and help you train the operator and mechanic.

5. Free beverage production technology and process configuration.

6. We can help you to design the product line, workshop and provide turn-key project.
