Specifications
Brand Name :
JIAYUAN
Model Number :
DCGF
Certification :
CE SGS
Place of Origin :
China (mainland)
MOQ :
1set
Price :
USD5000 per set
Supply Ability :
100sets per year
Delivery Time :
35 working days
Packaging Details :
standard wooden cases
name :
carbonated drink bottling machine
function :
bottle washing filling capping
suitable bottle :
PET bottle
bottle volume :
330-2000ml
filling material :
carbonated drink, sparking water, soda water ...
capacity :
2000-24000BPH
Material :
SUS304
Warranty :
1 year
Description

Carbonated beverage rising filling capping 3 in 1 machine

Specifications

carbonated beverage bottling machine
1.Product: Beverages
2.Bottle: PET
3.PLC control, touch screen, SS304

carbonated beverage bottling machine

Product Description

The series of machine are the integrated rinsing, filling and capping machine, suitable for filling various PET bottled carbonated beverages.

charateristic

1. Bottles are transported with neck clipped in the filling monoblock, which features1Bottles with same and nearly same diameter can be changed easily with no need to adjust equipments. Even when bottles change a bit in diameter, you only need quite short time to change starwheels of bottle-block parts. This improvement helps the customer to ease operation and save time.2Be able to avoid second pollution from rubber clamp.

2. Bottle infeed by combination of infeed screw and infeed starwheel. Equipped with bottle jam protection device.

3. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and also saves rinsing water.

4. Adopt ring cylinder and equip CIP(SIP) cycling channel; high accurate and speed level favles are reasonably structured with accurate filling.

5. Use ZALKIN capping technology and magnetic contortion variation device to ensure stable and reliable capping quality which is suitable to high speed production line.

6. The height of bottle outfeeding conveyor does not need to be adjusted when changing bottle shape.

Technical parameter

odel

DCGF

16-12-6

DCGF

18-18-6

DCGF

24-24-8

DCGF

32-32-10

DCGF

40-40-12

DCGF

50-50-15
Washing No 16 18 24 32 40 50
Filling No 12 18 24 32 40 50
Capping No 6 6 8 10 12 15
Production Capacity(500ml) 3000BPH 5000BPH 8000BPH

12000

BPH

15000

BPH

18000

BPH
Install Capacity(KW) 3.5 4 4.8 7.6 8.3 9.6
Overall size 2450×1800×2400 2650×1900×2400 2900×2100×2400 4100×2400×2400 4550×2650×2400

5450×3210×2400

Machine pictures

Automatic Carbonated Drink Filling Machine With Good Service , Soda Filling Machine

Automatic Carbonated Drink Filling Machine With Good Service , Soda Filling Machine

washing

Automatic Carbonated Drink Filling Machine With Good Service , Soda Filling Machine

filling

Automatic Carbonated Drink Filling Machine With Good Service , Soda Filling Machine

capping

Automatic Carbonated Drink Filling Machine With Good Service , Soda Filling Machine

electrical system

Automatic Carbonated Drink Filling Machine With Good Service , Soda Filling Machine

3. The working process

The bottle enters into the rinsing part of three-in-one machine through air conveyor. The gripper installed on the rotary disk catches bottle and turns it over 180 degrees and makes the bottleneck face ground. In the special rinsing area, the nozzle on the gripper sprays juice to rinse bottle inwall. After rinsing and draining, the bottle turns over 180 degrees along the guide rail and make the bottleneck faces sky. Then rinsed bottle is transferred to the filling part through poking bottle starwheel. The bottle that enters into the filler is hold by neck holding plate. The filling valve acted by the cam can realize up and down. It adopts equal pressure filling way. The filling valve opens and begins filling when it moves down and touches thebottleneck, the filling valve move up and leave the bottleneck when it finishes filling, the full bottle is transferred to the capping part through hold neck transition poking wheel. The stop screwing knife holds the bottleneck, keeps bottle upright not rotating. The screw capping head keeps in revolution and autorotation. It can finish a whole capping course including catching, pressing, screwing, discharging through the action of the cam. The full bottle is transferred to bottle outlet conveyor to the next process through starwheel. The whole machine is enclosed with windows, the height of enclosed window is higher than the peak of the 3 in 1 machine, in the bottom of the enclosed window has return air outlet.

about our company

our main production lines:

1. bottling minereal/pure water production line;

2. barrel mineral/ pure water production line

3. bottling carbonated beverage production line (like coca cola);

4. bottling juice production line;

5. canning beverage production line;

6. glass bottle beer production line;

7. milk/tea filling&package line;

8. oil filling&package line;

Automatic Carbonated Drink Filling Machine With Good Service , Soda Filling Machine

our two workshops

Automatic Carbonated Drink Filling Machine With Good Service , Soda Filling Machine

certificates

Automatic Carbonated Drink Filling Machine With Good Service , Soda Filling Machine
