Mango Juice Bottling Production Line Hot Filling Machine Small Automatic 6.68 Kw
Mango Juice Bottling Production Line Hot Filling Machine Small Automatic 6.68 Kw
Specifications
Brand Name :
jiayuan
Model Number :
RCGF18-18-6
Certification :
CE,ISO,SGS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1 Set/Sets
Price :
US $15,000 - 800,000 / Set |
Supply Ability :
10 Set/Sets per Month
Delivery Time :
30 work days
Packaging Details :
wooden box
Type :
Filling Machine
Application :
Beverage, Food
Packaging Material :
Paper, Plastic, Wood
Automatic Grade :
Fully Auto
Dimension(L*W*H) :
2450*1800*2200mm
Weight :
3000kg
Power :
6.68kw
Material :
Food grade stainless steel
Filling type :
Normal pressure filling
Control system :
PLC control
Filling temperature :
Room temperature
Filling capacity :
6000BPH(500ml)
After-sales Service Provided :
Engineers available to service overseas
Warranty :
1 year for free
Description

Complete Hot Filling Machine Small Automatic Fruit Apple Orange Mango Juice Bottling Production Line

1) Feature

This filling machine is mainly designed for filling hot temperature liquid into glass bottle; For example juice, tea drinks etc which are made of concentrate juice. The final filling temperature will be around 85-90 degree centigrade; Once the thermal meter in juice filling machine is lower than the temperature, juice will be return to sterilizing machine again through return system. Glass bottle juice filling machine is different from plastic bottle. It will be optional and suggested to apply 4 in 1 filling machine, one more washing system is adopted to warm up the glass bottle in advance.

2) Technique parameter

RCGF18-18-6 RCGF24-24-8
Productivity 6000BPH 10000BPH
Rinsing Head 18 24
Filling Head 18 24
Capping Head 6 8
Bottle Volume 350ml~2000ml±10ml
Bottle Diameter φ50-92mm
Bottle Height 150-310 mm
Filling Tolerance ±2%
Cap Size 28mm and 30mm PE Standard Caps
Air Pressure 0.6MPa
Air Consumption 500 L/min
Filling Water Consumption 3 m3/h 6 m3/h
Rinsing Water Consumption 1 m3/h 2 m3/h
Motor Power 6.68kW 7.68kW
Voltage 380V
Dimension (L×W×H) 2450*1800*2200mm (L×W×H) 2750*2180*2200mm
Weight 3000kg 5300kg
Filling Principle Gravity Filling
Our advantage

Why choice us?

Design Ability All the machines designed by CAD
Manufacturing Ability Mechanical parts: high quality stainless steel, processed by CNC
Reliability Electrical parts from world famous suppliers
Professional

Focus on beverage and cosmetics packing machines

Exported to over 20 countries with good reputation

6 years Alibaba Golden supplier without complaint
Good Service Service include complete production line design, manufacturing, on-site installation & aftersales maintenance.
Profession on Export Authorized export licence.
Export Market

Our machine has been sold to more than 40 countries,almost of the customers are satisfiedwith the machines and our service.
