Pure Water 5 Gallon Water Filling Machine For Blue Barrel Production Line
Pure Water 5 Gallon Water Filling Machine For Blue Barrel Production Line
Specifications
Brand Name :
JIAYUAN
Model Number :
QGF-300
Certification :
CE,ISO,SGS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1piece
Price :
US $30,000 - 50000 / Set
Supply Ability :
10 Set/Sets per Month
Delivery Time :
30 working days
Packaging Details :
wooden box
Material :
stainless steel 304
Condition :
New
Application :
Beverage, Chemical, Food, Medical
Packaging Type :
Barrel,Bottles, Cartons
Automatic Grade :
Automatic
Driven Type :
Electric
Power :
3.8kw
Warranty :
1 year for free
Power supply :
380V/50HZ(adjustable)
Filling type :
Normal pressure filling
Processing Types :
Water
Dimension(L*W*H) :
3800*1300*1600MM
Filling bottle size :
1-5gallen/3-19L
Description

5 gallon pure water making machine for blue barreled production line

Product Description
5 gallon pure water making machine for blue barreled production line

Keyword: Water Filling Machine/Barreled Production Line/120barreled Production Line/5gallons production line/5gallons rinsing filling capping/5gallons barreled production line

Barreled drinking water production line

5 gallon pure water making machine for blue barreled production line

1.It has the following types:80 type,150 type,300 type,450 type,600 type,900 type.

2.It integrates bottle washer, filler and sealer into one unit. In order to achieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and bleaching are used in bottle washer,washing solution can be used circularly.

3.The sealer can seal barrel caps are aseptic and healthy,this line can also automatically carry out washing,sterilizing,filling, capping, counting and products discharging.It is a new kind of barreled water auto-producing line,which integrates mechanism, electricity and pneumatic technologies together.

Model QGF-80 QGF-150 QGF-300 QGF-450 QGF-600
Filling heads 1 1 2 3 4
Volume 18.9 18.9 18.9 18.9 18.9
Barrel size 270*490 270*490 270*490 270*490 270*490
Capacity 80 150 300
Gas pressure 0.4 -0.6 0.4 -0.6 0.4 -0.6 0.4 -0.6 0.4 -0.6
Gas consumption 0.37 0.37 0.6 0.8 1
Motor power 1.38 1.75 3.8 3.8 7.5
Motor voltage 380V/50HZ 380V/50HZ 380V/50HZ 380V/50HZ 380V/50HZ
Weight 500 700 1200 1600 2000
Dimension 2500*1100*1600 2800*1100*1600 3800*1300*1600 4200*1600*1600 4800*1800*1600

Pure Water 5 Gallon Water Filling Machine For Blue Barrel Production Line

Pure Water 5 Gallon Water Filling Machine For Blue Barrel Production Line

Pure Water 5 Gallon Water Filling Machine For Blue Barrel Production Line

Pure Water 5 Gallon Water Filling Machine For Blue Barrel Production Line

Kindly remind
Please kindly send us your requirements:
1, bottle vlolume
2, bottle materail (machines for glass bottle and plastic bottle are different)
3, how many bottlesper hour you want to produce ?
4, do you need this water filling machines only or whole water production line
Our Services

1.One year warranty for the whole system.

2.Free equipment installation and debugging.

3.After one year, we can help you to maintain the machine and the accessories are provided only one the cost price.

4.We can provide internship service and help you train the operator and mechanic.

5.Free beverage production technology and process configuration.

6We can help you to design the product line, workshop and provide turn-key project.

Why choice us?

Design Ability All the machines designed by CAD
Manufacturing Ability Mechanical parts: high quality stainless steel, processed by CNC
Reliability Electrical parts from world famous suppliers
Professional

Focus on beverage and cosmetics packing machines

Exported to over 20 countries with good reputation

6 years Alibaba Golden supplier without complaint
Good Service Service include complete production line design, manufacturing, on-site installation & aftersales maintenance.
